System Register Block
UG0331 User Guide Revision 15.0 692
Note: The weight values are as given in Ta ble 6 72, page 692.
22.3.18 Master Weight Configuration Register 1
Note: The weight values are as given in Ta ble 6 72, page 692.
The following table provides weight values, where <master> is IC, S, GIGE, FIC_0, FIC_1, PDMA,
HPDMA, USB, or G.
[24:20] SW_WEIGHT_FAB_1 0 Configures the round robin weight for fabric (FIC_1) master. It is
configurable from 1 to 32 (32 by default).
[19:15] SW_WEIGHT_FAB_0 0 Configures the round robin weight for fabric (FIC_0) master. It is
configurable from 1 to 32 (32 by default).
[14:10] SW_WEIGHT_GIGE 0 Configures the round robin weight for Ethernet master. It is
configurable from 1 to 32 (32 by default).
[9:5] SW_WEIGHT_S 0 Configures the round robin weight for S master. It is configurable from
1 to 32 (32 by default).
[4:0] SW_WEIGHT_IC 0 Configures the round robin weight for IC master. It is configurable from
1 to 32 (32 by default).
Table 671 • MASTER_WEIGHT1_CR
Bit
Number Name
Reset
Value Description
[31:15] Reserved 0
[14:10] SW_WEIGHT_G 0 Configures the round robin weight for G master. It is configurable from
1 to 32 (32 by default).
[9:5] SW_WEIGHT_USB 0 Configures the round robin weight for USB master. It is configurable
from 1 to 32 (32 by default).
[4:0] SW_WEIGHT_HPDMA 0 Configures the round robin weight for HPDMA master. It is
configurable from 1 to 32 (32 by default).
Table 672 • Programmable Weight Values
SW_WEIGHT_<master> Weight
032
11
22
33
..
..
..
28 28
29 29
30 30
31 31
Table 670 • MASTER_WEIGHT0_CR (continued)
