15.2.3 Initialization
The I
2
C peripheral can be initialized in the user application software by configuring the I
2
C Control
register and SOFT_RESET_CR system registry. The initialization sequence is as follows:
1. Release the I
2
C from reset by using SOFT_RESET_CR system registry (Tab l e 51 7 , page 540).
2. Enable I
2
C by writing ‘1’ to the ENS1 bit of Control Register.
3. Configure the serial clock rate by using CR0, CR1, and CR2 bits of Control Register.
4. Set the slave address to Slave0 Address Register (Slave0 Address Register).
15.2.3.1 I
2
C Reset
The I
2
C peripherals reset to zero on power-up and are held in reset until enabled. An option is provided
under software control to reset the I
2
C peripherals by writing to bit 11 or bit 12 in the System register,
SOFT_RESET_CR. The soft resets are encoded in the following table.
At power-up, the reset signals are asserted as 1. This keeps the I
2
C peripherals in a reset state. I
2
C
peripheral becomes active when the bit is set to 0, as shown in Table 518, page 541.
15.2.3.2 I
2
C Clock Requirements
The I2C_0 and I2C_1 peripherals are clocked by APB_0_CLK on APB bus 0 and APB_1_CLK on APB
bus 1. These clocks are derived from the main MSS clock M3_CLK. Each APB clock can be
programmed individually as M3_CLK divided by 1, 2, 4 or 8. Refer to the UG0449: SmartFusion2 and
IGLOO2 Clocking Resources User Guide for more information.
15.2.3.2.1 Baud Rate Clock
BCLK is a pulse-for-transmission speed control signal and is internally synchronized with the clock input.
BCLK is used to set the serial clock frequency from a clock sourced within the FPGA fabric when the
CR[2:0] bits in the Control register are set to 0b111(0x7). Otherwise, either APB_0_CLK or APB_1_CLK
is used to determine the serial clock frequency. The actual non-stretched serial bus clock frequency can
be calculated based on the settings in the CR[2:0] fields of the Control register and the frequencies of
APB_0_CLK or APB_1_CLK and BCLK. Refer to the Control Register, page 551 for more information on
bit settings.
15.2.3.2.2 Clock Stretching
The I
2
C peripherals support the clock stretching feature as defined in Philips I
2
C v2.1 specifications. This
addresses the condition where the I
2
C slave is unable to meet the clock speed provided by the I
2
C
master and needs to slow down. Care should be taken so that the slowest I
2
C device does not dominate
the bus performance. The I
2
C slave is allowed to hold down the clock if it needs to reduce the bus speed.
The I
2
C master reads back the clock signal after releasing it to a High state and waits until the line goes
High.
Clock stretching is a common practice. However, the total bandwidth of the shared bus might significantly
decrease. Estimating the impact of clock stretching is required to share I
2
C bus among multiple devices.
Table 518 • Soft Reset Bit Definitions For I
2
C Peripherals
Bit
Number Name R/W Reset Value Description
12 I2C1_SOFTRESETR R/W 1 Controls reset input to I2C_1
0: Release I2C_1 from reset
1: Keep I2C_1 in reset (reset value)
11 I2C0_SOFTRESET R/W 1 Controls reset input to I2C_0
0: Release I2C_0 from reset
1: Keep I2C_0 in reset (reset value)
