MSS GPIO
UG0331 User Guide Revision 15.0 587
16.4.7.29 IOMUX CELL 39
I/O pad name: MMUART1_DSR_MGPIO14B
16.4.7.30 IOMUX CELL 40
I/O pad name: MMUART1_RI_MGPIO15B
16.4.7.31 IOMUX CELL 41
I/O pad name: MMUART1_DCD_MGPIO16B
16.4.7.32 IOMUX CELL 42
I/O pad name: MMUART1_TXD_USBC_DATA2__MGPIO24B
Table 574 • IOMUX CELL 39
I/O Pad Ports
IOMUXCELL Interface
MMUART_1 USB Controller GPIO[14] FPGA Fabric
IN DSR_1_IN NC GPIOB_IN[14] IN_A GND
OUT GND GND GPIO_OUT[14] IN_B GND
OE VDD GND GPIO_OE[14] OUT_A H2F_A[39]
OUT_B NC
Table 575 • IOMUX CELL 40
I/O Pad Ports
IOMUXCELL Interface
MMUART_1 USB Controller GPIO[15] FPGA Fabric
IN RI_1_IN NC GPIOB_IN[15] IN_A GND
OUT GND GND GPIO_OUT[15] IN_B F2H_SCP[40]
OE VDD GND GPIO_OE[15] OUT_A NC
OUT_B NC
Table 576 • IOMUX CELL 41
I/O Pad Ports
IOMUXCELL Interface
MMUART_1 USB Controller GPIO[16] FPGA Fabric
IN DCD_1_IN NC GPIOB_IN[16] IN_A GND
OUT GND GND GPIO_OUT[16] IN_B F2H_SCP[41]
OE VDD GND GPIO_OE[16] OUT_A NC
OUT_B NC
Table 577 • IOMUX CELL 42
I/O Pad Ports
IOMUXCELL Interface
MMUART_1 USB Controller GPIO[24] FPGA Fabric
IN TXD_1_IN USBC_DATAI[2] GPIOB_IN[24] IN_A F2H_GPIN[42]
OUT TXD_1_OUT DATAO[2] GPIO_OUT[24] IN_B F2H_SCP[42]
OE MMUART1_TE ~NDATAOE GPIO_OE[24] OUT_A H2F_A[42]
OUT_B H2F_B[42]
