CAN Controller
UG0331 User Guide Revision 15.0 463
The rest of the receive message buffers (RX_MSG1 to RX_MSG31) and register bits have the same
descriptions as the RX_MSG0 registers shown above. The following table lists the address offset for the
RX_MSG1 to RX_MSG31 registers.
Refer to RX_MSG0 buffer for description from Tabl e 450 , page 460 through Table 457, page 462.
Table 458 • Receive Message1 to Receive Message 31 and ECR Registers Description
Register Name Address Offset R/W Reset Value Description
RX_MSG1 Buffer 0x240-0x25C R/W 0 Receive Message1 buffer registers
RX_MSG2 Buffer 0x260-0x27C R/W 0 Receive Message2 buffer registers
RX_MSG3 Buffer 0x280-0x29C R/W 0 Receive Message3 buffer registers
RX_MSG4 Buffer 0x2A0-0x2BC R/W 0 Receive Message4 buffer registers
RX_MSG5 Buffer 0x2C0-0x2DC R/W 0 Receive Message5 buffer registers
RX_MSG6 Buffer 0x2E0-0x2FC R/W 0 Receive Message6 buffer registers
RX_MSG7 Buffer 0x300-0x31C R/W 0 Receive Message7 buffer registers
RX_MSG8 Buffer 0x320-0x33C R/W 0 Receive Message8 buffer registers
RX_MSG9 Buffer 0x340-0x35C R/W 0 Receive Message9 buffer registers
RX_MSG10 Buffer 0x360-0x37C R/W 0 Receive Message10 buffer registers
RX_MSG11 Buffer 0x380-0x39C R/W 0 Receive Message11 buffer registers
RX_MSG12 Buffer 0x3A0-0x3BC R/W 0 Receive Message12 buffer registers
RX_MSG13 Buffer 0x3C0-0x3DC R/W 0 Receive Message13 buffer registers
RX_MSG14 Buffer 0x3E0-0x3FC R/W 0 Receive Message14 buffer registers
RX_MSG15 Buffer 0x400-0x41C R/W 0 Receive Message15 buffer registers
RX_MSG16 Buffer 0x420-0x43C R/W 0 Receive Message16 buffer registers
RX_MSG17 Buffer 0x440-0x45C R/W 0 Receive Message17 buffer registers
RX_MSG18 Buffer 0x460-0x47C R/W 0 Receive Message18 buffer registers
RX_MSG19 Buffer 0x480-0x49C R/W 0 Receive Message19 buffer registers
RX_MSG20 Buffer 0x4A0-0x4BC R/W 0 Receive Message20 buffer registers
RX_MSG21 Buffer 0x4C0-0x4DC R/W 0 Receive Message21 buffer registers
RX_MSG22 Buffer 0x4E0-0x4FC R/W 0 Receive Message22 buffer registers
RX_MSG23 Buffer 0x500-0x51C R/W 0 Receive Message23 buffer registers
RX_MSG24 Buffer 0x520-0x53C R/W 0 Receive Message24 buffer registers
RX_MSG25 Buffer 0x540-0x55C R/W 0 Receive Message25 buffer registers
RX_MSG26 Buffer 0x560-0x57C R/W 0 Receive Message26 buffer registers
RX_MSG27 Buffer 0x580-0x59C R/W 0 Receive Message27 buffer registers
RX_MSG28 Buffer 0x5A0-0x5BC R/W 0 Receive Message28 buffer registers
RX_MSG29 Buffer 0x5C0-0x5DC R/W 0 Receive Message29 buffer registers
RX_MSG30 Buffer 0x5E0-0x5FC R/W 0 Receive Message30 buffer registers
RX_MSG31 Buffer 0x600-0x61C R/W 0 Receive Message31 buffer registers
