Fabric Interface Controller
UG0331 User Guide Revision 15.0 758
The following table lists the number of FICs available for use in each device.
24.1 Functional Description
This following sections provide a detailed description of the FIC subsystem.
Figure 327 • Fabric Interface Controller Block Diagram
The preceding figure shows a block diagram for the FIC. The FIC is a hard block; enabling or disabling it
will not consume any user logic. You can configure FIC_0 and FIC_1 independently from the Libero SoC
MSS configurator. The following configuration options are available.
• The MSS to the FPGA fabric interface
• Advanced AHB-Lite options
• The FPGA fabric Address Regions (MSS Master View)
Table 777 • Number of FICs Available for Use in Each Device
Device FIC Blocks
M2S005 1
1
1. Only FIC_0 is available.
M2S010
M2S025
M2S050 2
M2S060 1*
M2S090
M2S150 2
AHB Bus Matrix
AHB-Lite Master
Interface
AHB-Lite Master
Interface
AHB-Lite / APB
Slave Interface
AHB-Lite / APB
Master Interface
AHB-Lite / APB
Master Interface
AHB-Lite / APB
Slave Interface
AHB-LiteMSS AHB-Lite
AHB-Lite Slave
Interface
AHB-Lite Slave
Interface
Fabric Interface Controller
Fabric
