CAN Controller
UG0331 User Guide Revision 15.0 458
The following table lists the address offsets for the TX_MSG1 to TX_MSG31 registers.
Refer to TX_MSG0 buffer for description from Table 444, page 456 through Ta ble 4 47, page 457.
Table 448 • Transmit Message1 to Transmit Message31 Registers Description
Register Name
Address
Offset R/W
Reset
Value Description
TX_MSG1 Buffer 0x030-0x03C R/W 0 Transmit Message1 buffer registers
TX_MSG2 Buffer 0x0040-0x04C R/W 0 Transmit Message2 buffer registers
TX_MSG3 Buffer 0x050-0x05C R/W 0 Transmit Message3 buffer registers
TX_MSG4 Buffer 0x060-0x06C R/W 0 Transmit Message4 buffer registers
TX_MSG5 Buffer 0x070-0x07C R/W 0 Transmit Message5 buffer registers
TX_MSG6 Buffer 0x080-0x08C R/W 0 Transmit Message6 buffer registers
TX_MSG7 Buffer 0x090-0x09C R/W 0 Transmit Message7 buffer registers
TX_MSG8 Buffer 0x0A0-0x0AC R/W 0 Transmit Message8 buffer registers
TX_MSG9 Buffer 0x0B0-0x0BC R/W 0 Transmit Message9 buffer registers
TX_MSG10 Buffer 0x0C0-0x0CC R/W 0 Transmit Message10 buffer registers
TX_MSG11 Buffer 0x0D0-0x0DC R/W 0 Transmit Message11 buffer registers
TX_MSG12 Buffer 0x0E0-0x0EC R/W 0 Transmit Message12 buffer registers
TX_MSG13 Buffer 0x0F0-0x0FC R/W 0 Transmit Message13 buffer registers
TX_MSG14 Buffer 0x100-0X10C R/W 0 Transmit Message14 buffer registers
TX_MSG15 Buffer 0x110-0X11C R/W 0 Transmit Message15 buffer registers
TX_MSG16 Buffer 0x120-0X12C R/W 0 Transmit Message16 buffer registers
TX_MSG17 Buffer 0x130-0X13C R/W 0 Transmit Message17 buffer registers
TX_MSG18 Buffer 0x140-0X14C R/W 0 Transmit Message18 buffer registers
TX_MSG19 Buffer 0x150-0X15C R/W 0 Transmit Message19 buffer registers
TX_MSG20 Buffer 0x160-0X16C R/W 0 Transmit Message20 buffer registers
TX_MSG21 Buffer 0x170-0X17C R/W 0 Transmit Message21 buffer registers
TX_MSG22 Buffer 0x180-0X18C R/W 0 Transmit Message22 buffer registers
TX_MSG23 Buffer 0x190-0X19C R/W 0 Transmit Message23 buffer registers
TX_MSG24 Buffer 0x1A0-0X1AC R/W 0 Transmit Message24 buffer registers
TX_MSG25 Buffer 0x1B0-0X1BC R/W 0 Transmit Message25 buffer registers
TX_MSG26 Buffer 0x1C0-0X1CC R/W 0 Transmit Message26 buffer registers
TX_MSG27 Buffer 0x1D0-0X1DC R/W 0 Transmit Message27 buffer registers
TX_MSG28 Buffer 0x1E0-0X1EC R/W 0 Transmit Message28 buffer registers
TX_MSG29 Buffer 0x1F0-0X1FC R/W 0 Transmit Message29 buffer registers
TX_MSG30 Buffer 0x200-0X20C R/W 0 Transmit Message30 buffer registers
TX_MSG31 Buffer 0x210-0X21C R/W 0 Transmit Message31 buffer regist
ers
