Fabric Interface Interrupt Controller
UG0331 User Guide Revision 15.0 740
Each fabric MSS_INT_M2F signal can be triggered from one of the two possible scenarios:
• Dedicated interrupts
• Multiplexed group of interrupts
The selection of the MSS interrupt to a specific MSS_INT_M2F signal and making it available to the
FPGA Fabric is done in two stages:
• Select the group of interrupts: It can be done by setting Select_Mode bit of the M2F Interrupt Mode
Register.
• Enable the MSS interrupts: It can be done by writing to the appropriate FIIC INTERRUPT_ENABLE0
and INTERRUPT_ENABLE1 interrupt enable registers.
It is possible to overlay one interrupt signal with two interrupt sources. For example, enable a dedicated
interrupt and a group 0/1 interrupt. User logic in the fabric is responsible for determining the actual
source of the interrupt by reading the appropriate peripheral interrupt Status Registers and determining
which interrupt has occurred. Interrupts In and Out of the FIIC are asynchronous.
All interrupts originating from MSS blocks and fed into the FIIC are active high level sensitive signals.
Once asserted, the interrupt remains asserted until the user logic clears the appropriate MSS
peripheral interrupt clear register. MSS_INT_M2F interrupt signals are serviced by the FPGA fabric. The
exceptions to this are the SMBALERT and SMBSUS interrupts from the I2C peripheral. When these are
held asserted, they are cleared by the far end I2C device, after a firmware-initiated sequence of
operations. WDOGTIMEOUTINT is always passed straight through the block as M3_NMI.
F2M interrupts from the fabric are connected to the Cortex-M3 processor NVIC. MSS_INT_F2M [15:0],
the 16 F2M interrupts from user logic in the fabric, are routed directly to the Cortex-M3 processor NVIC.
F2M interrupts are level sensitive active high inputs.
Once asserted, user logic in the fabric must keep the interrupt asserted until it is cleared by the
Cortex-M3 processor firmware. The SmartFusion2 SoC FPGA FIIC does not synchronize fabric sourced
peripheral interrupts to the fabric clock or MSS clock.
Table 766 • Interrupt Line Signal Distribution
M2F Interrupt Signal Dedicated Select Group 0 Select Group 1
MSS_INT_M2F[0] SPIINT0 ENVM_INT0 HPD_XFR_ERR_INT
MSS_INT_M2F[1] SPIINT1 ENVM_INT1 MSSDDR_PLL_LOCK_INT
MSS_INT_M2F[2] I2C_INT0 USB_DMA_INT SW_ERRORINTERRUPT
MSS_INT_M2F[3] I2C_INT1 Reserved DDRB_INTR
MSS_INT_M2F[4] MMUART0_INTR I2C_SMBALERT0 ECCINTR
MSS_INT_M2F[5] MMUART1_INTR I2C_SMBSUS0 CACHE_ERRINTR
MSS_INT_M2F[6] MAC_INT I2C_SMBALERT1 SOFTINTERRUPT
MSS_INT_M2F[7] USB_MC_INT I2C_SMBSUS1 COMM_BLK_INTR
MSS_INT_M2F[8] PDMAINTERRUPT HPD_XFR_ERR_INT Reserved
MSS_INT_M2F[9] HPD_XFR_CMP_INT MSSDDR_PLL_LOCK_INT Reserved
MSS_INT_M2F[10] TIMER1_INTR SW_ERRORINTERRUPT Reserved
MSS_INT_M2F[11] TIMER2_INTR DDRB_INTR MDDR_IO_CALIB_INT
MSS_INT_M2F[12] CAN_INTR ECCINTR Reserved
MSS_INT_M2F[13] RTC_WAKEUP_INTR CACHE_ERRINTR FAB_PLL_LOCK_INT
MSS_INT_M2F[14] WDOGWAKEUPINT SOFTINTERRUPT FAB_PLL_LOCKLOST_INT
MSS_INT_M2F[15] MSSDDR_PLL_LOCKLOST_INT COMBLK_INTR FIC64_INT
