MSS GPIO
UG0331 User Guide Revision 15.0 581
16.4.7.7 IOMUX CELL 17
I/O pad name: SPI0_SDO_USBA_STP_MGPIO6A
16.4.7.8 IOMUX CELL 18
I/O pad name: SPI0_SS0_USBA_NXT_MGPIO7A
16.4.7.9 IOMUX CELL 19
I/O pad name: SPI0_SS1_USBA_DATA5_MGPIO8A
Table 552 • IOMUX CELL 17
I/O Pad Ports
IOMUXCELL Interface
SPI_0 USB Controller GPIO[6] FPGA Fabric
IN NC NC GPIOA_IN[6] IN_A F2H_GPIN[17]
OUT SPISDO_0_OUT STP GPIO_OUT[6] IN_B F2H_SCP[17]
OE SPIOEN_0 VDD GPIO_OE[6] OUT_A H2F_A[17]
OUT_B H2F_B[17]
Table 553 • IOMUX CELL 18
I/O Pad Ports
IOMUXCELL Interface
SPI_0 USB Controller GPIO[7] FPGA Fabric
IN SPISSI_0_IN USBA_NXT GPIOA_IN[7] IN_A F2H_GPIN[18]
OUT SPISS_0_OUT[0] GND GPIO_OUT[7] IN_B F2H_SCP[18]
OE SPI_0_MASTER GND GPIO_OE[7] OUT_A H2F_A[18]
OUT_B H2F_B[18]
Table 554 • IOMUX CELL 19
I/O Pad Ports
IOMUXCELL Interface
SPI_0 USB Controller GPIO[8] FPGA Fabric
IN NC USBA_DATAI[5] GPIOA_IN[8] IN_A F2H_GPIN[19]
OUT SPISS_0_OUT[1] DATAO[5] GPIO_OUT[8] IN_B F2H_SCP[19]
OE SPI_0_MASTER ~NDATAOE GPIO_OE[8] OUT_A H2F_A[19]
OUT_B H2F_B[19]
