Microsemi SmartFusion2 - Table 559 IOMUX CELL 24

MSS GPIO
UG0331 User Guide Revision 15.0 583
16.4.7.14 IO MUX CELL 24
I/O pad name: SPI0_SS6_MGPIO21A
16.4.7.15 IOMUX CELL 25
I/O pad name: SPI0_SS7_MGPIO22A
16.4.7.16 IOMUX CELL 26
I/O pad name: SPI1_SDI_MGPIO11A
Table 559 • IOMUX CELL 24
I/O Pad Ports
IOMUXCELL Interface
SPI_0 USB Controller GPIO[21] FPGA Fabric
IN NC NC GPIOA_IN[21] IN_A GND
OUT SPISS_0_OUT[6] GND GPIO_OUT[21] IN_B GND
OE SPI_0_MASTER GND GPIO_OE[21] OUT_A H2F_A[24]
OUT_B NC
Table 560 • IOMUX CELL 25
I/O Pad Ports
IOMUXCELL Interface
SPI_0 USB Controller GPIO[22] FPGA Fabric
IN NC NC GPIOA_IN[22] IN_A GND
OUT SPISS_0_OUT[7] GND GPIO_OUT[22] IN_B GND
OE SPI_0_MASTER GND GPIO_OE[22] OUT_A H2F_A[25]
OUT_B NC
Table 561 • IOMUX CELL 26
I/O Pad Ports
IOMUXCELL Interface
SPI_0 USB Controller GPIO[11] FPGA Fabric
IN SPISDI_1_IN NC GPIOA_IN[11] IN_A F2H_GPIN[26]
OUT GND GND GPIO_OUT[11] IN_B F2H_SCP[26]
OE GND GND GPIO_OE[11] OUT_A H2F_A[26]
OUT_B H2F_B[26]
