(SBus). Microsemi recommends that the Cortex-M3 processor firmware is stored in a separate
eSRAM from the data storage of other services.
7.1.4.11 Memory Security
After reset, all master ports on the AHB bus matrix are enabled. There are separate user-defined flash
configuration bits that control read and write access for each memory slave from various masters, which
are organized in groups. The pairing of the masters and the slaves with respect to the bits set in the
security registers are given in detail in the following table. Read access and write access can be
independently controlled by separate read and write flash bits. The detailed bit configuration of these S
registers is given in the System Register Block, page 670.
An access attempt by a master where the corresponding master port is blocked (by a flash configuration
bit setting) causes the AHB bus matrix to assert HRESP to the master and terminate the transaction. If a
blocked port is attempting a read access, the read data is returned as garbage. If the blocked port is
attempting a write, the write of data does not occur to any slave. In both cases, one of the
SW_ERRORSTATUS bits is asserted. DDR_FIC is not part of the AHB bus matrix but can be blocked
from accessing the MSS DDR (MDDR) subsystem.
Table 146 • Pairing of Masters and Slaves
SYSREG Register Masters
Slaves
MS0 MS1 MS2 MS3 MS6
eSRAM
0 eSRAM1 eNVM_0 eNVM_1
MSS DDR
Bridge
MM0_1_2_SECURITY MM0: M3 DCode bus, cache RW RW RW RW RW
MM1: M3 ICode bus RW RW RW RW RW
MM2: M3 system bus RW RW RW RW RW
MM4_5_FIC64_SECURITY MM4: FIC_0 RW RW RW RW RW
MM5: FIC_1 RW RW RW RW RW
DDR_FIC RW RW RW RW RW
MM3_6_7_8_SECURITY MM3: HPDMA RW RW RW RW RW
MM6: MAC RW RW RW RW RW
MM7: PDMA RW RW RW RW RW
MM8: USB RW RW RW RW RW
MM9_SECURITY MM9: System controller RW RW RW RW RW
