Ethernet MAC
UG0331 User Guide Revision 15.0 410
Table 362 • STATION_ADDRESS2
Bit Number Name Reset Value Description
[31:24] STATION ADDRESS 0x0 This field holds the fifth octet of the station address.
[23:16] STATION ADDRESS 0x0 This field holds the sixth octet of the station address.
Table 363 • FIFO_CFG0
Bit Number Name Reset Value Description
[31:21] Reserved 0x0 Reserved
20 ftfenrply 0x0 This is a read only bit.
When asserted, the FIFO transmit interface is enabled.
When de-asserted, the FIFO transmit interface is disabled.
The bit should be polled until it reaches the expected value.
19 stfenrply 0x0 This is a read only bit.
When asserted, the FIFO PE-MCXMAC transmit interface
module is enabled.
When de-asserted, the FIFO PE-MCXMAC transmit interface
module is disabled.
The bit should be polled until it reaches the expected value.
18 frfenrply 0x0 This is a read only bit.
When asserted, the FIFO receive interface module is
enabled.
When de-asserted, the FIFO receive interface module is
disabled.
The bit should be polled until it reaches the expected value.
17 srfenrply 0x0 This is a read only bit.
When asserted, the FIFO PE-MCXMAC receive interface
module is enabled.
When de-asserted, the FIFO PE-MCXMAC receive interface
module is disabled.
The bit should be polled until it reaches the expected value.
16 wtmenrply 0x0 When asserted, the FIFO PE-MCXMAC watermark module is
enabled.
When de-asserted, the FIFO PE-MCXMAC watermark
module is disabled.
The bit should be polled until it reaches the expected value.
[15:13] Reserved 0x0 Reserved
12 ftfenreq 0x0 When asserted, this bit requests for enabling the FIFO fabric
transmit interface module.
When de-asserted, this bit requests for disabling the FIFO
Fabric transmit interface module.
11 stfenreq 0x0 When asserted, this bit requests for enabling the FIFO
PE-MCXMAC transmit interface module.
When de-asserted, this bit requests for disabling the FIFO
PE-MCXMAC transmit interface module.
