Microsemi SmartFusion2 - USB EDAC Count

System Register Block
UG0331 User Guide Revision 15.0 716
22.3.63 USB EDAC Count
22.3.64 CAN EDAC Count
22.3.65 eSRAM0 EDAC Address Register
22.3.66 eSRAM1 EDAC Address Register
Table 720 • USB_EDAC_CNT
Bit
Number Name
Reset
Value Description
[31:16] USB_EDAC_CNT_2E 0 16-bit counter that counts the number of 2-bit errors for USB.
The counter will not roll back and will stay at its maximum
value.
[15:0] USB_EDAC_CNT_1E 0 16-bit counter that counts the number of 1-bit errors for USB.
The counter will not roll back and will stay at its maximum
value.
Table 721 • CAN_EDAC_CNT
Bit
Number Name
Reset
Value Description
[31:16] CAN_EDAC_CNT_2E 0 16-bit counter that counts the number of 2-bit errors for CAN.
The counter will not roll back and will stay at its maximum
value.
[15:0] CAN_EDAC_CNT_1E 0 16-bit counter that counts the number of 1-bit errors for CAN.
The counter will not roll back and will stay at its maximum
value.
Table 722 • ESRAM0_EDAC_ADR
Bit
Number Name
Reset
Value Description
[31:26] Reserved 0
[25:13] ESRAM0_EDAC_2E_AD 0 Stores the address from eSRAM0 on which a 2-bit SECDED
error has occurred.
[12:0] ESRAM0_EDAC_1E_AD 0 Stores the address from eSRAM0 on which a 1-bit SECDED
error has occurred.
Table 723 • ESRAM1_EDAC_ADR
Bit
Number Name
Reset
Value Description
[31:26] Reserved 0
[25:13] ESRAM1_EDAC_2E_AD 0 Stores the address from eSRAM1 on which a 2-bit SECDED
error has occurred.
[12:0] ESRAM1_EDAC_1E_AD 0 Stores the address from eSRAM1 on which a 1-bit SECDED
error has occurred.
