Embedded SRAM (eSRAM) Controllers
UG0331 User Guide Revision 15.0 205
Note: Refer to Figure 101, page 210 for more information on AHB Bus Matrix masters and slaves.
7 MM9_MS3_ALLOWED_W 1 Write security bits for master 9 to slave 3 (eNVM1). If not set,
master 9 will not have write access to slave 3.
6 MM9_MS3_ALLOWED_R 1 Read security bits for master 9 to slave 3 (eNVM1). If not set,
master 9 will not have read access to slave 3.
5 MM9_MS2_ALLOWED_W 1 Write security bits for master 9 to slave 2 (eNVM0). If not set,
master 9 will not have write access to slave 2.
4 MM9_MS2_ALLOWED_R 1 Read security bits for master 9 to slave 2 (eNVM0). If not set,
master 9 will not have read access to slave 2.
3 MM9_MS1_ALLOWED_W 1 Write security bits for master 9 to slave 1 (eSRAM1]) If not set,
master 9 will not have write access to slave 1.
2 MM9_MS1_ALLOWED_R 1 Read security bits for master 9 to slave 1 (eSRAM1). If not set,
master 9 will not have read access to slave 1.
1 MM9_MS0_ALLOWED_W 1 Write security bits for master 9 to slave 0 (eSRAM0). If not set,
master 9 will not have write access to slave 0.
0 MM9_MS0_ALLOWED_R 1 Read security bits for master 9 to slave 0 (eSRAM0). If not set,
master 9 will not have read access to slave 0.
Table 135 • EDAC_SR
Bit
Number Name
Reset
Value Description
[31:14] Reserved 0 Reserved
13 CAN_EDAC_2E 0 Updated by CAN when a 2-bit SECDED error has been detected for
RAM memory.
12 CAN_EDAC_1E 0 Updated by CAN when a 1-bit SECDED error has been detected and
is corrected for RAM memory.
11 USB_EDAC_2E 0 Updated by USB when a 2-bit SECDED error has been detected for
RAM memory.
10 USB_EDAC_1E 0 Updated by USB when a 1-bit SECDED error has been detected and
is corrected for RAM memory.
9 MAC_EDAC_RX_2E 0 Updated by Ethernet when a 2-bit SECDED error has been detected
for Rx RAM memory.
8 MAC_EDAC_RX_1E 0 Updated by Ethernet when a 1-bit SECDED error has been detected
and is corrected for Rx RAM memory.
7 MAC_EDAC_TX_2E 0 Updated by Ethernet when a 2-bit SECDED error has been detected
for Tx RAM memory.
6 MAC_EDAC_TX_E 0 Updated by Ethernet when a 1-bit SECDED error has been detected
and is corrected for Tx RAM memory.
5 Reserved 0 Reserved
4 Reserved 0 Reserved
Table 134 • MM9_SECURITY (continued)
Bit
Number Name
Reset
Value Description
