Microsemi SmartFusion2 - Page 238

Embedded SRAM (eSRAM) Controllers
UG0331 User Guide Revision 15.0 204
Note: Refer to Figure 101, page 210 for more information on AHB Bus Matrix masters and slaves.
Table 133 • MM3_6_7_8_SECURITY
Bit
Number Name
Reset
Value Description
[31:10] Reserved 0 Reserved
9 MM3_6_7_8_MS6_ALLOWED_W 1 Write security bits for masters 3, 6, 7, and 8 to slave 6 (MSS
DDR bridge). If not set, masters 3, 6, 7, and 8 will not have
write access to slave 6.
8 MM3_6_7_8_MS6_ALLOWED_R 1 Read security bits for masters 3, 6, 7, and 8 to slave 6 (MSS
DDR bridge). If not set, masters 3, 6, 7, and 8 will not have
read access to slave 6.
7 MM3_6_7_8_MS3_ALLOWED_W 1 Write security bits for masters 3, 6, 7, and 8 to slave 3
(eNVM1). If not set, masters 3, 6, 7, and 8 will not have write
access to slave 3.
6 MM3_6_7_8_MS3_ALLOWED_R 1 Read security bits for masters 3, 6, 7, and 8 to slave 3
(eNVM1). If not set, masters 3, 6, 7, and 8 will not have read
access to slave 3.
5 MM3_6_7_8_MS2_ALLOWED_W 1 Write security bits for masters 3, 6, 7, and 8 to slave 2
(eNVM0). If not set, masters 3, 6, 7, and 8 will not have write
access to slave 2.
4 MM3_6_7_8_MS2_ALLOWED_R 1 Read security bits for masters 3, 6, 7, and 8 to slave 2
(eNVM0). If not set, masters 3, 6, 7, and 8 will not have read
access to slave 2.
3 MM3_6_7_8_MS1_ALLOWED_W 1 Write security bits for masters 3, 6, 7, and 8 to slave 1
(eSRAM1). If not set, masters 3, 6, 7, and 8 will not have
write access to slave 1.
2 MM3_6_7_8_MS1_ALLOWED_R 1 Read security bits for masters 3, 6, 7, and 8 to slave 1
(eSRAM1). If not set, masters 3, 6, 7, and 8 will not have
read access to slave 1.
1 MM3_6_7_8_MS0_ALLOWED_W 1 Write security bits for masters 3, 6, 7, and 8 to slave 0
(eSRAM0). If not set, masters 3, 6, 7, and 8 will not have
write access to slave 0.
0 MM3_6_7_8_MS0_ALLOWED_R 1 Read security bits for masters 3, 6, 7, and 8 to slave 0
(eSRAM0). If not set, masters 3, 6, 7, and 8 will not have
read access to slave 0.
Table 134 • MM9_SECURITY
Bit
Number Name
Reset
Value Description
[31:10] Reserved 0 Reserved
9 MM9_MS6_ALLOWED_W 1 Write security bits for master 9 to slave 6 (MSS DDR bridge). If
not set, master 9 will not have write access to slave 6.
8 MM9_MS6_ALLOWED_R 1 Read security bits for master 9 to slave 6 (MSS DDR bridge). If
not set, master 9 will not have read access to slave 6.
