Ethernet MAC
UG0331 User Guide Revision 15.0 425
6 C1RCD 0x0 Carry register 1 RCDE counter carry bit
5 C1RCS 0x0 Carry register 1 RCSE counter carry bit
4 C1RUN 0x0 Carry register 1 RUND counter carry bit
3 C1ROV 0x0 Carry register 1 ROVR counter carry bit
2 C1RFR 0x0 Carry register 1 RFRG counter carry bit
1 C1RJB 0x0 Carry register 1 RJBR counter carry bit
0 C1RDR 0x0 Carry register 1 RDRP counter carry bit
Table 422 • CAR2
Bit Number Name Reset Value Description
[31:20] Reserved 0x0 Reserved
19 C2TJB 0x0 Carry register 2 TJBR counter carry bit
18 C2TFC 0x0 Carry register 2 TXFC counter carry bit
17 C2TCF 0x0 Carry register 2 TXCF counter carry bit
16 C2TOV 0x0 Carry register 2 TOVR counter carry bit
15 C2TUN 0x0 Carry register 2 TUND counter carry bit
14 C2TFG 0x0 Carry register 2 TFRG counter carry bit
13 C2TBY 0x0 Carry register 2 TBYT counter carry bit
12 C2TPK 0x0 Carry register 2 TPKT counter carry bit
11 C2TMC 0x0 Carry register 2 TMCA counter carry bit
10 C2TBC 0x0 Carry register 2 TBCA counter carry bit
9 C2TPF 0x0 Carry register 2 TXPF counter carry bit
8 C2TDF 0x0 Carry register 2 TDFR counter carry bit
7 C2TED 0x0 Carry register 2 TEDF counter carry bit
6 C2TSC 0x0 Carry register 2 TSCL counter carry bit
5 C2TMA 0x0 Carry register 2 TMCL counter carry bit
4 C2TLC 0x0 Carry register 2 TLCL counter carry bit
3 C2TXC 0x0 Carry register 2 TXCL counter carry bit
2 C2TNC 0x0 Carry register 2 TNCL counter carry bit
1 C2TPH 0x0 Carry register 2 TPFH counter carry bit
0 C2TDP 0x0 Carry register 2 TDRP counter carry bit
Table 421 • CAR1 (continued)
