High Performance DMA Controller
UG0331 User Guide Revision 15.0 252
8.4.1.6 Descriptor 0 Destination Address Register
8.4.1.7 Descriptor 1 Destination Address Register
8.4.1.8 Descriptor 2 Destination Address Register
8.4.1.9 Descriptor 3 Destination Address Register
8.4.1.9.1 Notes on the Destination Address Register (DAR)
• Address is word aligned at the start.
• Address increments on each successful transfer at the destination end.
• HPDMA controller starts reading the data from source memory and transfers to destination memory.
• Software can write all 32-bit destination addresses to prevent non-word aligned transfers at the start
and 2 LSBs, 1:0, are masked in the hardware.
• The destination address will be updated in the same field when the descriptor transfer is in progress.
Table 155 • HPDMAD0DAR_REG
Bit Number Name Reset Value Description
31:0 HPDMADAR_DCP0_DST_ADRS 0x00 Descriptor 0 destination end memory start address
Table 156 • HPDMAD1DAR_REG
Bit Number Name Reset Value Description
31:0 HPDMADAR_DCP1_DST_ADRS 0x00 Descriptor 1 destination end memory start address
Table 157 • HPDMAD2DAR_REG
Bit Number Name Reset Value Description
31:0 HPDMADAR_DCP2_DST_ADRS 0x00 Descriptor 2 destination end memory start address
Table 158 • HPDMAD3DAR_REG
Bit Number Name Reset Value Description
31:0 HPDMADAR_DCP3_DST_ADRS 0x00 Descriptor 3 destination end memory start address
