7.1.4.1 eSRAM Remap
The AHB bus matrix supports remapping the eSRAM address space into code space that Cortex-M3
processor can use. Both eSRAM blocks can be remapped to appear at the bottom of Cortex-M3
processor code space as shown in the preceding figure. The amount of space available to
Cortex-M3 processor as code space depends on ECC as indicated below:
• When ECC is ON, the two eSRAM blocks (64 KB) can be remapped, but ECC sections of eSRAM (8
KB) cannot be used by the Cortex-M3 processor.
• When ECC is OFF, the two eSRAM blocks (64 KB) can be remapped, and the ECC sections of
eSRAM (8 KB) can also be used by the Cortex-M3 processor. These 8 KB are available at a different
address.The resultant memory map is illustrated in the following figure.
Figure 113 • Memory Map after eSRAM Remap (64 KB eSRAM)
In default mode, the Cortex-M3 processor firmware boots from eNVM. However, as shown in the
preceding figure, it is also possible to get the firmware to boot from eSRAM by re-mapping eSRAM to
location zero. Code shadowing is supported to facilitate this.
Memory Map of
Cortex-M3 Processor
Memory Map of System
Controller, FPGA Fabric
Master, Ethernet MAC,
Peripheral DMA
FPGA Fabric FIC Region5 FPGA Fabric FIC Region5 0xF0000000 - 0xFFFFFFFF
0xE0000000 - 0xEFFFFFFF
DDR_0 Space 3 DDR_0 Space 3 0xD0000000 - 0xDFFFFFFF
DDR_0 Space 2 DDR_0 Space 2 0xC0000000 - 0xCFFFFFFF
DDR_0 Space 1 DDR_0 Space 1 0xB0000000 - 0xBFFFFFFF
DDR_0 Space 0 DDR_0 Space 0 0xA0000000 - 0xAFFFFFFF
FPGA Fabric FIC Region4 FPGA Fabric FIC Region4 0x90000000 - 0x9FFFFFFF
FPGA Fabric FIC Region3 FPGA Fabric FIC Region3 0x80000000 - 0x8FFFFFFF
FPGA Fabric FIC Region2 FPGA Fabric FIC Region2 0x70000000 - 0x7FFFFFFF
0x60100000 - 0x6FFFFFFF
AHB-to-eNVM_1 Registers AHB-to-eNVM_1 Registers 0x600C0000 - 0x600FFFFF
AHB-to-eNVM_0 Registers AHB-to-eNVM_0 Registers 0x60080000 - 0x600BFFFF
eNVM_1 eNVM_1 0x60040000 - 0x6007FFFF
eNVM_0 eNVM_0 0x60000000 - 0x6003FFFF
FPGA Fabric FIC Region1 FPGA Fabric FIC Region1 0x50000000 - 0x5FFFFFFF
Peripheral bit-band
alias region of Cortex-M3
processor
0x44000000 - 0x4FFFFFFF
Peripherals (BB View) 0x42000000 - 0x43FFFFFF
0x40410000 - 0x41FFFFFF
Cache Back door 0x40400000 - 0x4040FFFF
0x40044000 - 0x403FFFFF
{
USB USB 0x40043000 - 0x40043FFF
0x40042000 - 0x40042FFF
Ethernet MAC Control Ethernet MAC Control 0x40041000 - 0x40041FFF
0x40039000 - 0x40040FFF
SYSREG SYSREG 0x40038000 - 0x40038FFF
(63 K space
allocation
for devices
outside MSS)
0x40030000 - 0x40037FFF
Config DDR_1, PCIe_0, PCIe_1, etc. Config DDR_1, PCIe_0, PCIe_1, etc. 0x40020400 - 0x4002FFFF
Config DDR_0 Config DDR_0 0x40020000 - 0x400203FF
0x40018000 - 0x4001FFFF
RTC RTC 0x40017000 - 0x40017FFF
COMBLK COMBLK 0x40016000 - 0x40016FFF
CAN CAN 0x40015000 - 0x40015FFF
High Performance DMA High Performance DMA 0x40014000 - 0x40014FFF
MSS GPIO MSS GPIO 0x40013000 - 0x40013FFF
I2C_1 I2C_1 0x40012000 - 0x40012FFF
SPI_1 SPI_1 0x40011000 - 0x40011FFF
UART_1 UART_1 0x40010000 - 0x40010FFF
0x40007000 - 0x4000FFFF
Fabric Interface Interrupt Controller Fabric Interface Interrupt Controller 0x40006000 - 0x40006FFF
Watchdog Watchdog 0x40005000 - 0x40005FFF
Timer Timer 0x40004000 - 0x40004FFF
Peripheral DMA Control Peripheral DMA Control 0x40003000 - 0x40003FFF
I2C_0 I2C_0 0x40002000 - 0x40002FFF
SPI_0 SPI_0 0x40001000 - 0x40001FFF
UART_0 UART_0 0x40000000 - 0x40000FFF
FPGA Fabric FIC Region0 FPGA Fabric FIC Region0 0x30000000 - 0x3FFFFFFF
SRAM bit-band alias region
of Cortex-M3 processor
0x24000000 - 0x2FFFFFFF
eSRAM_0/eSRAM_1(BB View)
0x22000000 - 0x23FFFFFF
0x20014000 - 0x21FFFFFF
ECC eSRAM_1 ECC eSRAM_1 0x20012000 - 0x20013FFF
ECC eSRAM_0 ECC eSRAM_0 0x20010000 - 0x20011FFF
Cortex-M3 Processor System
region
eSRAM_1 eSRAM_1 0x20008000 - 0x2000FFFF
eSRAM_0 eSRAM_0 0x20000000 - 0x20007FFF
0x10000000 - 0x1FFFFFFF DDR_0 Space 0(Mirrored) 0x00080000 - 0x1FFFFFFF
Cortex-M3 processor code
region
0x00180000 - 0x0FFFFFFF
e N V M ( F a b r i c )
Virtual View
0x0007FFFF
Visible only to
FPGA fabric
master
0x00100000 - 0x00170000
eNVM (Remap View)
0x00010000 - 0x000FFFFF
0x00000000 - 0x0000FFFF
eSRAM0 and eSRAM1 (Mirrored) 0x00000000
}
{
