Microsemi SmartFusion2 - Table 764 MSS_IOMUXSEL5 [N][2:0]; Table 765 MSS_IOMUXSEL4[N][2:0]

System Register Block
UG0331 User Guide Revision 15.0 737
22.3.105.1MSS_IOMUXSEL5[N][2:0]
22.3.105.2MSS_IO_MUXSEL4[N][2:0]
Table 764 • MSS_IOMUXSEL5 [N][2:0]
Bit 0 Bit 1 Bit 2 Function
0 0 0 Output of I/O cell comes from output of interface Serial Comms of IOMUXCELL
0 0 1 Output of I/O cell comes from output of interface MSS GPIO of IOMUXCELL
0 1 0 Output of I/O cell comes from output of interface USB Controller of
IOMUXCELL
0 1 1 Output of I/O cell is connected to '0'
1 0 0 Output of I/O cell is connected to '1'
1 0 1 Reserved
1 1 0 Reserved
1 1 1 Reserved
Table 765 • MSS_IOMUXSEL4[N][2:0]
Bit 0 Bit 1 Bit2 Function
0 0 0 Output of I/O cell comes from output of interface Serial Comms of IOMUXCELL
0 0 1 Output of I/O cell comes from output of interface MSS GPIO of IOMUXCELL
0 1 0 Output of I/O cell comes from output of interface USB Controller of IOMUXCELL
0 1 1 Output of I/O cell is connected to '0'
1 0 0 Output of I/O cell is connected to '1'
1 0 1 Reserved
1 1 0 Reserved
1 1 1 Reserved
