Ethernet MAC
UG0331 User Guide Revision 15.0 399
Minimal configuration, required for MAC to make it functional in 1000 Mbps mode of operation, is given
below:
CFG1= 32'h0000_0035 //Rx/Tx flow control enable, Rx/Tx-Enable
CFG2 = 32'h0000_7202 //Preamble=7, byteMode, CRC-enable
STATION_ADDRESS1 = 32'hA5A4_A3A2 //Station Address 1-4
STATION_ADDRESS2 = 32'hA1A0_0000 //Station Address 5-6
FIFO_CFG0 = 32'h0000_FF00 //Enable FIFO transmit and receive modules
FIFO_CFG3 = 32'h007F_FFFF // Tx-FIFO high watermark=128
11.8 EMAC Register Bit Definitions
The following tables are the bit definitions of the registers present in EMAC.
Table 339 • DMA_TX_CTRL
Bit
Number Name
Reset
Value Description
[31:1] Reserved 0x0 Reserved
0 Transmit control 0x0 TxEnable: Setting this bit enables DMA transmit packet transfers.
The bit is cleared by the built-in DMA controller whenever it encounters a
Tx Underrun or Bus Error state.
Table 340 • DMA_TX_DESC
Bit
Number Name
Reset
Value Description
[31:2] Top 30 bits of
Descriptor
Address
0x0. When TxEnable is set by the host, the built-in DMA controller reads this
register to discover the location in the host memory of the first transmit
packet descriptor.
[1:0] Ignored by the
DMA controller
0x0 All descriptors are 32-bit aligned in the host memory.
Table 341 • DMA_TX_STATUS
Bit Number Name Reset Value Description
[31:24] Reserved 0x0 Reserved
[23:16] TxPktCount 0x0 The 8-bit transmit packet counter that is incremented whenever the
built-in DMA controller successfully transfers a packet, and is
decremented whenever the host writes a '1' to bit '0' in this register.
[16:4] Reserved 0x0 Reserved
3 BusError 0x0 When set, this indicates that a host slave split, retry or error
response is received by the DMA controller.
2 Reserved 0x0 Reserved
1 TxUnderrun 0x0 Set whenever the DMA controller reads a '1' for the empty flag in
the descriptor.
0 TxPktSent 0x0 When set, this indicates that one or more packets have been
successfully transferred.
Writing a '1' to this bit reduces the TxPktCount value by one. The bit
is cleared whenever TxPktCount is zero.
