Fabric Interface Interrupt Controller

UG0331 User Guide Revision 15.0 742

The following figure shows the FIIC Configurator.

3. Select either or both check boxes per the application need.

Use Fabric to MSS Interrupt: Use this option to expose the MSS_INT_F2M interrupt port.

MSS_INT_F2M signals are then available to be used in the design.

Use MSS to Fabric Interrupt: Use this option to expose MSS_INT_M2F, M3_NMI and COM-

M_BLK_INT interrupts ports. These signals are then available to be used in the design.

Figure 323 • FIIC Configurator
