3.6.4.4.3 Restrictions
In these instructions:
•
Rn
must not be PC.
•
Rt
must not be SP and must not be PC.
3.6.4.4.4 Condition Flags
These instructions do not change the flags.
Examples
STRBTEQ R4, [R7] ; Conditionally store least significant byte in
; R4 to an address in R7, with unprivileged access
LDRHT R2, [R2, #8] ; Load halfword value from an address equal to
; sum of R2 and 8 into R2, with unprivileged access.
3.6.4.5 LDR, PC-relative
Load register from memory.
3.6.4.5.1 Syntax
LDR{type}{cond} Rt, label
LDRD{cond} Rt, Rt2, label ; Load two words
where:
• type is one of:
• B: unsigned byte, zero extend to 32 bits.
• SB: signed byte, sign extend to 32 bits.
• H: unsigned halfword, zero extend to 32 bits.
• SH: signed halfword, sign extend to 32 bits.
• -: omit, for word.
• cond is an optional condition code, see Conditional Execution, page 55.
• Rt is the register to load or store.
• Rt2 is the second register to load or store.
• label is a PC-relative expression. See PC-relative Expressions, page 55.
3.6.4.5.2 Operation
LDR
loads a register with a value from a PC-relative memory address. The memory address is specified
by a label or by an offset from the PC.
The value to load or store can be a byte, halfword, or word. For load instructions, bytes and halfwords
can either be signed or unsigned. See Address Alignment, page 55.
label
must be within a limited range of the current instruction. The following table shows the possible
offsets between
label
and the PC.
Note: You might have to use the
.W
suffix to get the maximum offset range. See Instruction Width Selection,
page 58.
Table 32 • Offset Ranges
Instruction type Offset range
Word, halfword, signed halfword, byte, signed byte -4095 to 4095
Two words -1020 to 1020
