MSS GPIO
UG0331 User Guide Revision 15.0 575
GPIO_13_CFG 0x34 R/W 0x0 Configuration register for GPIO 13
GPIO_14_CFG 0x38 R/W 0x0 Configuration register for GPIO 14
GPIO_15_CFG 0x3C R/W 0x0 Configuration register for GPIO 15
GPIO_16_CFG 0x40 R/W 0x0 Configuration register for GPIO 16
GPIO_17_CFG 0x44 R/W 0x0 Configuration register for GPIO 17
GPIO_18_CFG 0x48 R/W 0x0 Configuration register for GPIO 18
GPIO_19_CFG 0x4C R/W 0x0 Configuration register for GPIO 19
GPIO_20_CFG 0x50 R/W 0x0 Configuration register for GPIO 20
GPIO_21_CFG 0x54 R/W 0x0 Configuration register for GPIO 21
GPIO_22_CFG 0x58 R/W 0x0 Configuration register for GPIO 22
GPIO_23_CFG 0x5C R/W 0x0 Configuration register for GPIO 23
GPIO_24_CFG 0x60 R/W 0x0 Configuration register for GPIO 24
GPIO_25_CFG 0x64 R/W 0x0 Configuration register for GPIO 25
GPIO_26_CFG 0x68 R/W 0x0 Configuration register for GPIO 26
GPIO_27_CFG 0x6C R/W 0x0 Configuration register for GPIO 27
GPIO_28_CFG 0x70 R/W 0x0 Configuration register for GPIO 28
GPIO_29_CFG 0x74 R/W 0x0 Configuration register for GPIO 29
GPIO_30_CFG 0x78 R/W 0x0 Configuration register for GPIO 30
GPIO_31_CFG 0x7c R/W 0x0 Configuration register for GPIO 31
GPIO_IRQ 0x80 R/W 0x0 Read Modify Write per interrupt bit.
GPIO_IN 0x84 R 0x0 GPIO input register – Read-only for input
configured Ports.
GPIO_OUT 0x88 R/W 0x0 GPIO output register – Writeable/Readable
for output configured ports. No action
required for input configured ports.
Table 538 • MSS GPIO Register Map (continued)
