3 Spectrum Analyzer Mode

3.5 ACP Measurement

3.5.15.5 Trace Function

Contains controls to:

–

Copy and Exchange traces

–

Preset or Clear all traces

From Trace

Selects the trace to be copied to or exchanged with the "To Trace" on page 1752

when a "Copy" on page 1752 or "Exchange" on page 1753 is performed

Preset 1

To Trace

Selects the trace to be copied from or exchanged with the "From Trace" on page

1752 when a "Copy" on page 1752 or "Exchange" on page 1753 is performed

Preset 2

Copy

Executes a Trace Copy based on the "From Trace" on page 1752 and "To Trace" on

page 1752 parameters. The copy operation is from the From Trace to the To Trace.

The action is performed once.

The X-Axis settings and domain of a trace are also copied.

Remote Command For Swept SA Measurement (in SA Mode):

:TRACe:COPY TRACE1 | … | TRACE6, TRACE1 | … | TRACE6

For all other measurements:

:TRACe:<meas>:COPY TRACe1 | TRACe2 | TRACe3, TRACe1 | TRACe2 | TRACe3

where <meas> is the identifier for the current measurement

Note that the format of the TRACe<n> parameter differs from that for the Swept SA Measurement

Example Copy Trace 1 to Trace 3 and put Trace 3 in Update=Off, Display=On

:TRAC:COPY TRACE1,TRACE3

Notes The command is of the form:

:TRACe:COPY <source_trace>,<dest_trace>

Dependencies When Signal ID is on, this key is grayed-out

1128 Spectrum Analyzer Mode User's &Programmer's Reference
