Keysight x-series User Manual

3 Spectrum Analyzer Mode
3.7 Burst Power Measurement
Every marker has another marker to which it is relative. This marker is referred to as
the “reference marker” for that marker. This attribute is set by the Marker,
Properties, Relative To key. The marker must be a Delta marker to make this
attribute relevant. If it is a Delta marker, the reference marker determines how the
marker is controlled and how its value is displayed. A marker cannot be relative to
itself.
Remote
Command
:CALCulate:TXPower:MARKer[1]|2|...|12:REFerence <integer>
:CALCulate:TXPower:MARKer[1]|2|...|12:REFerence?
Example
:CALC:TXP:MARK:REF 10
:CALC:TXP:MARK:REF?
Notes Causes the marker specified with the subopcode to become selected
Range (for SCPI command): 1 to 12. If the range is exceeded the value is clipped
A marker cannot be relative to itself so that choice is not available, and if sent from SCPI generates
error -221: “Settings conflict; marker cannot be relative to itself”
The query returns a single value (the specified marker numbers relative marker)
Couplings The act of specifying the selected marker’s reference marker makes the selected marker a Delta marker
If the reference marker is off it is turned on in Fixed or Normal mode at the delta marker location
Preset The preset default “Relative To” marker (reference marker) is the next higher numbered marker (current
marker +1). For example, if marker 2 is selected, then it’s default reference marker is marker 3. The
exception is marker 12, which has a default reference of marker 1
Set to the defaults by Restore Mode Defaults. This is not reset by Marker Off, All Markers Off, or Preset
State Saved Saved in instrument state. Not affected by Marker Off and hence not affected by Preset or power cycle
Min 1
Max 12
Annunciation Appears in the marker label of a Delta marker
Marker Trace
Assigns the specified marker to the designated trace.
Remote Command
:CALCulate:TXPower:MARKer[1]|2|...|12:TRACe RFENvelope | MAXHold | MINHold
:CALCulate:TXPower:MARKer[1]|2|...|12:TRACe?
Example
:CALC:TXP:MARK:TRAC MAXH
:CALC:TXP:MARK:TRAC?
Dependencies If Max Hold under Trace is Off, Max Hold is grayed out
Preset
RFENvelope
State Saved Yes
Range RF Envelope|Max Hold RF Envelope|Min Hold RF Envelope
Backwards
Compatibility SCPI
:CALCulate:BPOWer:MARKer[1]|2|...|12:TRACe
Included for backwards compatibility only. Not recommended for use in new designs
1316 Spectrum Analyzer Mode User's &Programmer's Reference
