4 System
4.6 Alignments
4.6.3.2 Path Delay Correction On/Off(Remote Command only)
On/Off the path delay correction to enable the calibration data on the source of the
module.
Remote
Command
:CALibration:PDELay:CORRection ON | OFF
:CALibration:PDELay:CORRection?
Example
:CAL:PDEL:CORR ON
Notes If the Path Delay Calibration has never been performed and there is no calibration correction data in the
controller, an alert is generated
Preset
OFF
Range
ON|OFF
4.6.4 Show Alignment Statistics
Shows alignment information you can use to ensure that the instrument is operating
in a specific manner. The Show Alignment Statistics screen is where you can view
time and temperature information.
Values displayed are only updated when the Show Alignment Statistics screen is
invoked. They are not updated while the Show Alignment Statistics screen is being
displayed. The remote commands that access this information obtain current values.
Note that some of these statistics only display if your instrument supports them; for
example, Last Source Align Now All Time only shows up in instruments which
contain a source which supports auto alignments.
An example of the Show Alignment Statistics screen would be similar to:
2131 Spectrum Analyzer Mode User's &Programmer's Reference
