Keysight x-series User Manual

3 Spectrum Analyzer Mode
3.2 Swept SA Measurement
Setting Name
(readback)
Setting Name
(verbose)
Max Mixer
Level Preset
Value, dBm
Max Mixer
Level minimum
value, dBm
Max Mixer
Level
maximum
value, dBm
dynamic range
COMPression
Compression-
limited dynamic
range
−3 −10 +30
Remote Command
[:SENSe]:POWer[:RF]:MIXer:RULEs NORMal | TOI | COMPression
[:SENSe]:POWer[:RF]:MIXer:RULEs?
Example
:POW:MIX:RULE:COMP
Dependencies Only appears in the Swept SA and RTSA measurements
Preset
NORM
3.2.3.3 Range (Non-attenuator models)
Only available for Keysight’s modular signal analyzers and certain other Keysight
products, such as VXT and M941xE.
State Saved No
Range
Represents the amplitude of the largest sinusoidal signal that could be present
within the IF without being clipped by the ADC. For signals with high peak-to-
average ratios, the range may need to exceed the rms signal power by a significant
amount to avoid clipping.
This is a measurement global setting.
Remote
Command
[:SENSe]:POWer[:RF]:RANGe <real>
[:SENSe]:POWer[:RF]:RANGe?
Example
:POW:RANG 10 dBm
:POW:RANG?
Notes The MIN and MAX values are affected by the External Gain parameters, and by the Center Frequency
The hardware compensates for frequency response and alters the Range setting
Preset 0 dBm
State Saved Yes
Min/Max –/+100
Annotation Meas Bar
224 Spectrum Analyzer Mode User's &Programmer's Reference
