Keysight x-series User Manual

6 Input/Output
6.1 RF Source
Command
:SOURce:RADio:ARB:NR5G:PHASe:FILTer:BANDwidth?
Example
:SOUR:RAD:ARB:NR5G:PHAS:FILT:BAND 99MHz
:SOUR:RAD:ARB:NR5G:PHAS:FILT:BAND?
Preset 100 MHz
Min 10 Hz
Max 1200 MHz
Select Waveform
Lets you select a waveform segment or sequence to be played by the ARB player.
Presents you with a list of waveform segments files and waveform sequence files.
The list of waveform segment files and waveform sequence files contains the names
of all the waveform segments and waveform sequence files currently loaded into
ARB playback memory.
Waveform sequences are not available in E7760B.
Waveforms formatted as *.mat, *.csv and *.txt are supported by models with a
built-in source, such as VXT and EXM.
NOTE
To load a file from the hard drive into ARB memory, go to the Recall, Waveform
dialog
NOTE
Selecting a waveform file does not result in automatic adjustments to burst
timing; that adjustment occurs only when a waveform is loaded to ARB memory.
Remote
Command
:SOURce:RADio:ARB:WAVeform <string>
:SOURce:RADio:ARB:WAVeform?
Example
:SOUR:RAD:ARB:WAV "test_waveform.bin"
Notes If the intended waveform is not in the memory yet, then issuing this command invokes ARB loading
operation first, which involves a delay of unpredictable length, so this command should be followed by
*OPC?, which holds off subsequent commands until the loading operation is complete
<string> - specifies the name of the waveform segment or waveform sequence to be played by the
ARB
Sequence Analyzer Mode only:
–
If Include Source is Yes, and you attempt to play a waveform sequence but not all the required
waveform segments are in the ARB playback memory, the application rejects the loading operation
and an error is generated
–
If Include Source is No, and you attempt to play a waveform sequence but not all the required
waveform segments are contained in the ARB playback memory, the application attempts to load
the required segments from either the default directory or the current directory. If the ARB memory
Spectrum Analyzer Mode User's &Programmer's Reference 2305

Keysight x-series Specifications

General

Analysis Bandwidth	Up to 1 GHz (depending on model)
Real-Time Bandwidth	Up to 1 GHz (depending on model)
Form Factor	Benchtop
Connectivity	LAN, USB, GPIB
Resolution Bandwidth	1 Hz to 10 MHz (depending on model)
