4 System
4.11 SCPI Recorder
and recording will be stopped, unless the recording limit is increased.
NOTE
To maintain the integrity of recording, stop recording
before
sending remote
commands to the instrument. Changes made to the instrument via remote SCPI
are
not
recorded.
4.11.2 Recording Limit
When "Continuous SCPI Recording" on page 2193 is enabled, every change you
make is recorded into the recording system, which can lead to extremely large
recordings.
This value limits how much content can be saved into the recording table. You may
change this number to suit your needs, but the value cannot be less than 0 or
greater than 500. When the recording length reaches the limit, a warning is
displayed to indicate that the recording size has reached the limit and recording will
be stopped.
The default limit is 250. If the limit is reduced after recording entries are added, the
reduced count cannot be less than the current number of entries in the recording. If
the newly-entered limit is smaller than the existing number of entries, then the
actual new limit is set to the current number of entries. Increasing the limit will
increase memory consumption.
4.11.3 Play All
Clicking this control causes each of the entries in the SCPI Recorder table to be
executed.
If execution results in any errors, then a message box showing the SCPI command,
and its corresponding error are displayed after play has completed.
4.11.4 Play Selected
You can select a row in the SCPI recording table, then click Play Selected to play
that entry. Play Selected is disabled if the recording table is empty, or when no row
is selected. You can then select another row and play the selection, but, if you want
to play back in a particular order, you must execute the plays in the desired
sequence.
After playing the selected entry, the selected row is moved down by one entry.
Spectrum Analyzer Mode User's &Programmer's Reference 2194
