3 Spectrum Analyzer Mode
3.8 Spurious Emissions Measurement
4.7kHz, 47kHz, 470kHz, 5MHz, 5MHz, 5MHz, 5MHz, 300kHz, 300kHz, 300kHz, 300kHz, 300kHz,
300kHz, 300kHz, 300kHz, 300kHz, 300kHz, 300kHz, 300kHz, 300kHz
5G NR Mode:
100 Hz, 1 kHz, 10 kHz, 100 kHz, 100 kHz, 100 kHz, 100 kHz, 300 kHz, 300 kHz, 300 kHz, 300 kHz, 300
kHz, 300 kHz, 300 kHz, 300 kHz, 300 kHz, 300 kHz, 300 kHz, 300 kHz, 300 kHz
State Saved Saved in instrument state
Min/Max 1 Hz/50 MHz
Backwards
Compatibility
SCPI
[:SENSe]:SPURious[:RANGe][:LIST]:BWIDth:VIDeo
Auto Function
Remote
Command
[:SENSe]:SPURious[:RANGe][:LIST]:BANDwidth:VIDeo:AUTO OFF | ON | 0 | 1, OFF
| ON | 0 | 1, OFF | ON | 0 | 1, OFF | ON | 0 | 1, OFF | ON | 0 | 1, OFF | ON
| 0 | 1, OFF | ON | 0 | 1, OFF | ON | 0 | 1, OFF | ON | 0 | 1, OFF | ON | 0
| 1, OFF | ON | 0 | 1, OFF | ON | 0 | 1, OFF | ON | 0 | 1, OFF | ON | 0 | 1,
OFF | ON | 0 | 1, OFF | ON | 0 | 1, OFF | ON | 0 | 1, OFF | ON | 0 | 1, OFF
| ON | 0 | 1, OFF | ON | 0 | 1
[:SENSe]:SPURious[:RANGe][:LIST]:BANDwidth:VIDeo:AUTO?
Example
:SPUR:BAND:VID:AUTO ON, ON, OFF, OFF, OFF, ON, ON, ON, OFF, OFF, OFF, OFF,
OFF, OFF, OFF, ON, ON, ON, ON, ON
:SPUR:BAND:VID:AUTO?
Preset
ON,ON,ON,ON,ON,ON,ON,ON,ON,ON,ON,ON,ON,ON,ON,ON,ON,ON,ON,ON
unless noted below
LTE, LTEAFDD, LTETDD, LTEATDD, MSR:
OFF, OFF, OFF, OFF, OFF, OFF, OFF, ON, ON, ON, ON, ON, ON, ON, ON, ON, ON,
ON, ON, ON
State Saved Saved in instrument state
Backwards
Compatibility
SCPI
[:SENSe]:SPURious[:RANGe][:LIST]:BWIDth:VIDeo:AUTO
Filter Type
Same as the Filter Type column under the Bandwidth tab. See"Filter Type" on page
1449.
Attenuation
Defines attenuation value for each range:
ON
The Attenuation value under AMPTD Y Scale is used
OFF
This value is used as mechanical attenuation value without electric attenuation
Spectrum Analyzer Mode User's &Programmer's Reference 1459
