3 Spectrum Analyzer Mode

3.2 Swept SA Measurement

EMC Standard

Lets you select NONE (no EMI standard), CISPr (CISPR 16-1-1), or MIL (MIL-461A).

Each standard has a unique way of determining the couplings between detectors

and RBWs, as well as its own set of available RBWs.

Note that "Auto Couple" on page 2017 has no effect on the EMC Standard setting.

Remote Command

[:SENSe]:EMC:STANdard[:SELect] NONE | CISPr | MIL

[:SENSe]:EMC:STANdard[:SELect]?

Example

:EMC:STAN CISP

Dependencies When the EMC Standard changes to CISPR or MIL, the RBW Filter Type and RBW BW controls are

grayed-out. The Filter Type is then always Gaussian; the Filter BW is chosen as appropriate for the

filter and the standard. See the BW key description

When the EMC Standard changes to None, the Filter Type is set to Gaussian and the Filter BW is set to

-3 dB

Only appears with Option EMC installed and licensed. If not, the command generates a message

Couplings The auto rules for detector select Peak for any trace in Auto when the EMI Standard is CISPR or MIL

Choosing a CISPR detector or CISPR presets automatically picks the CISPR Standard, however

switching from a CISPR detector has no impact on EMC Standard

State Saved Saved in instrument state

Backwards Compatibility Command

Notes This command is mapped to :EMC:STANdard with the following mappings: EMI=>CISPr, SAN

=>None, and if the legacy command comes in with the OFF parameter, it sets EMC Standard to None

and Res BW to Manual .The query returns “OFF” if Res BW in Manual, otherwise “EMI” if EMC

Standard is CISPR or MIL, and “SAN” if EMC Standard is None

Dependencies Only appears in N/W6141A applications or with Option EMC installed and licensed. If not, the

command generates a message

Preset

SAN

Backwards

Compatibility SCPI

[:SENSe]:BANDwidth|BWIDth[:RESolution]:MODE EMI | SAN | OFF

[:SENSe]:BANDwidth|BWIDth[:RESolution]:MODE?

CISPR Presets

This group of controls lets you easily set up the instrument for CISPR

measurements.

This topic contains the following sections:

424 Spectrum Analyzer Mode User's &Programmer's Reference
