4 System
4.7 Licensing
NOTE
This feature is not available if Option SF1 is installed.
For help on licensing, select Help in the menu bar at the top of the License Explorer
window.
4.7.8 Install License (Remote Command Only)
Used to add a license to the instrument.
An example of such a command would be as below. The parameter is a unique 120-
character code for each license.
SYST:LKEY “N9073A-
1FP”,”027253AD27F83CDA5673A9BA5F427FDA5E4F25AEB1017638211AC9F60D9C639FE53973590
9C551DE0A91”
Another example using one of the optional clauses.
SYST:LKEY "N9063EM0E-
1FP,2019.0330","02220210867E187713C9AFD4C90EA0DE2B674615DD0255798EE5B237A146A0D
4E411E0ABFE04D3CAFDFA","ISSUED=30-Mar-2018"
NOTE
This command does not work for Transportable, Network or USB Portable
licenses.
Remote
Command
:SYSTem:LKEY <"OptionInfo">, <"LicenseIn-
fo">,<"Optional1">,<"Optional2">,<"Optional3">,<"Optional4">,<"Optional5">
Notes <”OptionInfo”> contains the feature and the version. You must specify the feature but can omit the
version. If you omit the version, the system regards it as the latest one, since the system knows which
version is supported for each feature
<”LicenseInfo”> contains the signature, the expiration date, and serial number for transport if
transportable. You must specify the signature, but you can omit the other information. If you omit the
expiration date, the system regards it as permanent. If you omit the serial number, the system regards it as
non-transportable. As a result, this supports reverse compatibility
<”Optional#”> are optional parameters that may be needed to match the information in the original
license
4.7.9 Remove License (Remote Command Only)
Removes a particular license.
An example of such a command would be as below. The parameter is a unique 120-
character code for each license.
SYST:LKEY:DEL “N9073A-
Spectrum Analyzer Mode User's &Programmer's Reference 2186
