5 Preset
The Preset functions can be accessed in two ways:
–
By pressing the Mode Preset or User Preset front panel keys:
–
From the menu "Preset Dropdown" on page 2206, which appears when you press
the green Preset icon (in the upper right corner of the display):
Types of Preset
The table below shows all possible presets, their corresponding SCPI commands
and front-panel access methods.
Instrument settings are tiered in scope from those local to the current measurement
to those global to all measurements and Modes. There are presets tailored to each
scope. The table identifies the scope of each preset type.
NOTE
To get a Mode back to a fully predefined state, you should execute "Restore
Mode Defaults" on page 2209 and "Input/Output Preset" on page 2210, but since
Input/Output Preset is a global function, it affects all Modes.
Type Of Preset SCPI Command Scope of Preset Front Panel
Access
"Auto Couple" on
page 2017
:COUPle ALL
Local to the current measurement,
only affects Auto/Man variables
Meas Setup
menu
Meas Preset
:CONFigure:<meas>
Local to the current measurement
Does not preset the RF Source
Meas Setup
menu
"Mode Preset" on
page 2207
:SYSTem:PRESet
Local to the current Mode, global to
all measurements in the Mode,
affects most but not all parameters in
the Mode
Does not affect Input/Output or
System variables
Presets the RF Source
Mode Preset key
"Preset
Dropdown" on
page 2206
"Restore Mode
:INSTrument:DEFault
Local to the current Mode, global to "Preset
X-Series Signal Analyzers
Spectrum Analyzer Mode User's &Programmer's Reference
2203

Keysight x-series Specifications

General

Analysis Bandwidth	Up to 1 GHz (depending on model)
Real-Time Bandwidth	Up to 1 GHz (depending on model)
Form Factor	Benchtop
Connectivity	LAN, USB, GPIB
Resolution Bandwidth	1 Hz to 10 MHz (depending on model)
