Keysight x-series User Manual

3 Spectrum Analyzer Mode
3.9 SEM Measurement
3.9.15 Display
Lets you configure display items for the current Mode, Measurement View or
Window.
3.9.15.1 Meas Display
Contains controls for setting up the display for the current Measurement, View or
Window.
Limit Lines
Toggles Limit Lines display for this measurement On or Off.
Remote Command
:CALCulate:SEMask:LLINe:STATe ON | OFF | 1 | 0
:CALCulate:SEMask:LLINe:STATe?
Example
:CALC:SEM:LLIN:STAT OFF
:CALC:SEM:LLIN:STAT?
Preset
ON
State Saved Saved in instrument state
Range
ON|OFF
3.9.15.2 Annotation
Contains controls for setting up the annotation for the current Mode or
Measurement.
Graticule
Turns the display graticule On or Off for all windows with graticules in all
measurements in the current Mode. Also turns the graticule Y-Axis annotation on
and off.
Remote
Command
:DISPlay:GRATicule[:STATe] OFF | ON | 0 | 1
:DISPlay:GRATicule[:STATe]?
Example
:DISP:GRAT OFF
Notes The graticule is the set of horizontal and vertical lines that make up the grid/divisions for the X-Axis and
Y-Axis
Preset
ON
1604 Spectrum Analyzer Mode User's &Programmer's Reference
