3 Spectrum Analyzer Mode
3.4 Occupied BW Measurement
The spur avoidance function is not available for:
–
M9410A/11A with EP6 option at frequency above 6 GHz
–
M9415A/16A at frequency below 380 MHz and above 12.3 GHz
–
M9410E/11E/15E/16E at frequency below 380 MHz and above 25.9 GHz
Remote Command
[:SENSe]:OBWidth:SAVoid[:STATe] OFF | ON | 0 | 1
[:SENSe]:OBWidth:SAVoid[:STATe]?
Example
:OBW:SAV ON
:OBW:SAV?
Dependencies Only appears in VXT models M9410A/11A/15A/16A and M9410E/11E/15E/16E
Preset
OFF
State Saved Saved in instrument state
Range
OFF|ON
Meas Setup Summary Table
Lets you view and access many of the parameters in the Meas Setup menus on one
screen.
Auto Couple
Immediately puts all Auto/Man functions into Auto. Auto Couple is confined to the
current measurement only. It does not affect other measurements in the Mode.
In the Auto state, Auto/Man functions are said to be “coupled”, meaning their values
change as you make changes to other values in the measurement. This helps ensure
accurate measurements and optimum dynamic range. Auto Couple is an immediate
action function, and when it is executed, all the Auto/Man controls for the current
measurement are set to Auto, and all measurement settings coupled to the
Auto/Man parameters are automatically set to their optimal values.
For further details of measurement-specific settings (if any), see "Measurement-
Specific Details" on page 804 below.
Remote
Command
:COUPle ALL
Example
:COUP ALL
Backwards
Compatibility
SCPI
:COUPLE ALL | NONE
Backwards :COUP:NONE puts all Auto/Man parameters in manual mode, decoupling all the coupled instrument
Spectrum Analyzer Mode User's &Programmer's Reference 803
