3 Spectrum Analyzer Mode
3.10 TOI Measurement
State Saved Saved in instrument state
Prefilter Presets
Meas Mode Preset
SPEC BASIC OFF
WAV BASIC, WCDMA, WLAN, LTEAFDD, LTEATDD, 5GNR, VMA OFF
MON WCDMA, WLAN, LTEAFDD, LTEATDD, 5GNR, VMA OFF
RHO WCDMA OFF
CDP WCDMA OFF
PCON WCDMA OFF
EVMQ WCDMA OFF
CHP WCDMA, WLAN, LTEAFDD, LTEATDD, 5GNR, VMA, SA OFF
OBW WCDMA, WLAN, LTEAFDD, LTEATDD, 5GNR, VMA, SA OFF
ACP WCDMA, LTEAFDD, LTEATDD, 5GNR, VMA, SA OFF
SEM WCDMA, WLAN, LTEAFDD, LTEATDD, 5GNR, VMA, SA OFF
PST WCDMA, WLAN, LTEAFDD, LTEATDD, 5GNR, VMA, SA OFF
PVT WLAN, LTEAFDD, LTEATDD, 5GNR OFF
EVM WLAN, LTEAFDD, LTEATDD, 5GNR OFF
FLAT WLAN OFF
EVMM WLAN OFF
CEVM LTEAFDD, LTEATDD OFF
PAVT 5GNR, VMA OFF
DDEM VMA OFF
OFDM VMA OFF
SAN SA ON
HARM SA ON
3.10.4 BW
Opens the bandwidth (BW) menu, which contains controls for the Resolution
Bandwidth and Video Bandwidth functions of the instrument.
The Resolution BW functions control filter bandwidth and filter type. There are two
filter types, Gaussian and Flattop. The Gaussian filters have a response curve that is
parabolic on a log scale. The Flattop filter shape is a close approximation of a
rectangular filter.
3.10.4.1 Settings
Contains the basic bandwidth functions. In this measurement, it is the only tab
under BW.
Spectrum Analyzer Mode User's &Programmer's Reference 1805
