Keysight x-series User Manual

3 Spectrum Analyzer Mode
3.9 SEM Measurement
Compatibility
SCPI
Ref Position
Sets the reference position for the X axis to Left, Center or Right.
Remote
Command
:DISPlay:SEMask:WINDow[1]:TRACe:X[:SCALe]:RPOSition LEFT | CENTer | RIGHt
:DISPlay:SEMask:WINDow[1]:TRACe:X[:SCALe]:RPOSition?
Example
:DISP:SEM:WIND:TRAC:X:RPOS LEFT
:DISP:SEM:WIND:TRAC:X:RPOS?
Preset
CENTer
State Saved Saved in instrument state
Range Left|Center|Right
Backwards
Compatibility
SCPI
:DISPlay:SEMask:VIEW[1]:WINDow[1]:TRACe:X[:SCALe]:RPOSition
Auto Scaling
Toggles the scale coupling function On or Off.
Remote
Command
:DISPlay:SEMask:WINDow[1]:TRACe:X[:SCALe]:COUPle 0 | 1 | OFF | ON
:DISPlay:SEMask:WINDow[1]:TRACe:X[:SCALe]:COUPle?
Example
:DISP:SEM:WIND:TRAC:X:COUP ON
:DISP:SEM:WIND:TRAC:X:COUP?
Couplings When Auto Scaling is ON and the Restart front-panel key is pressed, this function automatically
determines the scale per division and reference values based on the measurement results
When you set a value to either "Scale/Div" on page 1731 or "Ref Value" on page 1731 manually, Auto
Scaling automatically changes to OFF
Preset
ON
State Saved Saved in instrument state
Range
OFF|ON
Backwards
Compatibility
SCPI
:DISPlay:SEMask:VIEW[1]:WINDow[1]:TRACe:X[:SCALe]:COUPle
1732 Spectrum Analyzer Mode User's &Programmer's Reference
