7 Save/Recall/Print
7.3 Save
7.3.7.1 Select Correction
Selects the specific Correction to be saved, for example, Correction 1.
Preset Not part of a Preset, but reset to Correction 1 by Restore Input/Output Defaults
Survives a shutdown
7.3.8 Correction Group
Selects Correction Group as the data type to be exported with a save request. The
next step is to select the Save As key in the Save Data menu.
Remote Command
:MMEMory:STORe:CORRection:GROup <filename>
Example Save Correction Group to the file myAmpcorGroup.csv:
:MMEM:STOR:CORR:GRO "D:\myAmpcorGroup.csv"
Notes If the save is initiated via SCPI, and the file already exists, the file and the directory will be overwritten
Using the C: drive is strongly discouraged, since it runs the risk of being overwritten during an
instrument software upgrade
Both single and double quotes are supported for any filename parameter over SCPI
Dependencies This file type is supported in EMI Receiver and Spectrum Analyzer Modes, if Option EMC or EMI
Receiver mode is present
Annotation After save is complete, an advisory is displayed in the message bar confirming which file was saved
Correction Group File
A Correction Group file contains the correction group settings (that is, Antenna unit,
break, description, and comment) range table and correction files data. Corrections
files are text files in .csv (comma-separated value) format, to make them
importable into Excel or other spreadsheet programs.
7.3.9 SCPI Recorder
Contains controls to allow you to save SCPI recordings.
7.3.9.1 Save To File
Saves SCPI recording content to a file. For details of the SCPI Recording feature, see
"SCPI Recorder" on page 2193.
There are two possible file formats:
2617 Spectrum Analyzer Mode User's &Programmer's Reference
