Keysight x-series User Manual

3 Spectrum Analyzer Mode
3.5 ACP Measurement
Modes Values
Radio Test
REL, REL, REL, REL, REL, REL
State Saved Saved in instrument state
Range
ABSolute|AND|OR|RELative
Backwards
Compatibility
SCPI
[:SENSe]:MCPower:OFFSet[1]|2:LIST:TEST
Offset Frequency Define
Allows you to select “Offset” definition:
CTOCenter
From the lowermost carrier center frequency (for lower offset), the uppermost carrier center frequency
(for upper offset) to the center frequency of each Offset Integ BW
CTOEdge
From the lowermost carrier center frequency (for lower offset), the uppermost carrier center frequency
(for upper offset) to the closest edge frequency of each Offset Integ BW
ETOCenter
From the lowermost carrier center frequency - spacing of this carrier /2 (for lower offset), the
uppermost carrier center frequency + spacing of this carrier /2 (for upper offset) to the center
frequency of each Offset Integ BW
ETOEdge
From the lowermost carrier center frequency - spacing of this carrier /2 (for lower offset), the
uppermost carrier center frequency + spacing of this carrier /2 (for upper offset) to the closest edge
frequency of each Offset Integ BW
STOCenter
From either the lower or upper sub-block edge frequency to the center frequency of each Offset Integ
BW
STOEdge
From either the lower or upper sub-block edge frequency to the closest edge frequency of each Offset
Integ BW
SCTOCenter
5G NR Mode only
From the center frequency of sub-block** to the center frequency of each Offset Integ BW
** sub-block (bandwidth) = BW
channel,block
which is defined in each 3GPP standard,
regardless of “Measure Carrier” for the uppermost and the lowermost carriers being
Enabled or Disabled. When the Number of Component Carrier within each sub-
block = 1, sub-block (bandwidth) = BW
channel
= 2 x F
offset,RAT
.
See "Diagram for Offset Freq Define" on page 1040
Mode: MSR, LTEAFDD, LTEATDD
Remote
Command
[:SENSe]:ACPower:OFFSet[1]|2:INNer:TYPE CTOCenter | CTOEdge | ETOCenter |
ETOEdge | STOCenter | STOEdge
[:SENSe]:ACPower:OFFSet[1]|2:INNer:TYPE?
Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink
1038 Spectrum Analyzer Mode User's &Programmer's Reference

Keysight x-series Specifications

General

Analysis Bandwidth	Up to 1 GHz (depending on model)
Real-Time Bandwidth	Up to 1 GHz (depending on model)
Form Factor	Benchtop
Connectivity	LAN, USB, GPIB
Resolution Bandwidth	1 Hz to 10 MHz (depending on model)
