3 Spectrum Analyzer Mode

3.8 Spurious Emissions Measurement

that they determine their attributes and behaviors, and it is to that trace that they go

when they become Normal markers.

Specifying a Marker Trace manually or with this command associates the marker

with the specified trace. If the marker is not OFF, it moves the marker from the trace

it was on to the new trace. If the marker is OFF, it stays off but is now associated with

the specified trace.

The query returns the number of the trace on which the marker is currently placed.

Remote

Command

:CALCulate:SPURious:MARKer[1]|2|…|12:TRACe:ATTached?

Example

:CALC:SPUR:MARK2:TRAC:ATT TRAC2

:CALC:SPUR:MARK2:TRAC:ATT?

Notes A marker may be placed on a blanked and/or inactive trace, even though the trace is not visible and/or

updating

An application may register a trace name to be displayed on the control instead of a trace number

Couplings The state of Marker Trace is not affected by "Auto Couple" on page 2017

Sending the remote command causes the addressed marker to become selected

Preset

TRACe1

State Saved Saved in instrument state

Range

TRACe1|TRACe2|TRACe3

Marker Settings Diagram

Lets you configure the Marker system using a visual utility. It is the same as "Marker

Settings Diagram" on page 1426 under Settings.

3.8.8 Meas Setup

Contains functions for setting up the measurement parameters, and for setting up

parameters global to all measurements in the Mode.

3.8.8.1 Settings

Contains frequently-used Meas Setup functions, to which you will want the fastest

access.

Avg/Hold Num

Specifies the number of measurement averages used to calculate the measurement

result. The average is displayed at the end of each sweep.

Spectrum Analyzer Mode User's &Programmer's Reference 1431
