Keysight x-series User Manual

3 Spectrum Analyzer Mode
3.5 ACP Measurement
State Saved Saved in instrument state
Min/Max -150.0 dB/50.0 dB
Fail Mask
Accesses a menu that lets you select one of the logics for the fail conditions
between the measurement results and the test limits. The setting defines the type of
testing to be done at any custom offset frequencies. The measured powers are
tested against the absolute values defined with [:SENSe]:ACP:OFFSet[n]
[:OUTer]:LIST:ABSolute, or the relative values defined with
[:SENSe]:ACP:OFFSet[n][:OUTer]:LIST:RPSDensity and [:SENSe]:ACP:OFFSet[n]
[:OUTer]:LIST:RCARrier.
You can turn off (not use) specific offsets with [:SENSe]:ACP:OFFSet[n]
[:OUTer]:LIST:STATe.
Absolute
ABSolute
Fail is shown if one of the absolute ACP measurement results is larger than the limit for
Abs Limit
Relative
RELative
Fail is shown if one of the relative ACP measurement results is larger than the limit for
Rel Lim (Car) or Rel Lim (PSD)
Abs AND Rel
AND
Fail is shown if one of the absolute ACP measurement results is larger than the limit for
Abs Limitand one of the relative ACP measurement results is larger than the limit for
Rel Lim (Car) or Rel Lim (PSD)
Abs OR Rel
OR
Fail is shown if one of the absolute ACP measurement results is larger than the limit for
Abs Limitor one of the relative ACP measurement results is larger than the limit for Rel
Lim (Car) or Rel Lim (PSD)
Remote
Command
[:SENSe]:ACPower:OFFSet[1]|2[:OUTer]:LIST:TEST ABSolute | AND | OR |
RELative,…
[:SENSe]:ACPower:OFFSet[1]|2[:OUTer]:LIST:TEST?
Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink
Example
:ACP:OFFS2:LIST:TEST ABS,ABS,ABS,ABS,ABS,ABS
:ACP:OFFS2:LIST:TEST?
Notes Some Modes do not support Offset subopcode 2. In those cases, commands with subopcode 2 are
accepted without error but ignored
Preset When "Max Num of Offsets" on page 1010 is 12, the preset value of Offset G ~ L is the same as the
Offset F value
Modes Values
SA, WCDMA
REL, REL, REL, REL, REL, REL | REL, REL, REL,
REL, REL, REL
LTEAFDD, LTEATDD, 5G
NR, MSR
AND, AND, AND, AND, AND, AND | AND, AND, AND,
AND, AND, AND
Spectrum Analyzer Mode User's &Programmer's Reference 1037
