6 Input/Output
6.2 Input
Example
:MIX:BIAS 0
:MIX:BIAS?
Preset Unaffected by Preset, but set to OFF (0) by Restore Input/Output Defaults
State Saved Saved in instrument state
Min -10mA
Max 10mA
Annunciation When the bias is turned on this (together with the bias polarity) is indicated in the Meas Bar with a plus
or minus sign:
otherwise, it reads “Off”
Auto Function
Remote Command
[:SENSe]:MIXer:BIAS:STATe OFF | ON | 0 | 1
[:SENSe]:MIXer:BIAS:STATe?
Example
:MIX:BIAS:STAT 0
:MIX:BIAS:STAT?
Preset
OFF
6.2.13.3 Table Type
Determines the Custom Mixer configuration type. You can choose: Single Row,
Harmonic Switching, or Doubler Switching. For details, see "Available Types" on
page 2368.
The Harmonic Table can be configured as:
–
A single row (meaning only one harmonic number is used and the LO Doubler is
either on or off)
–
Two rows where the harmonic number switches between the first row and the
second
–
Two rows where the LO Doubler state switches between the first row and the
second
Available Types
Table Type Behavior
Single Row The External Mixer always stays in the same Harmonic Number and the LO Doubler is either on or off and
does not change state during a sweep. You may change the Harmonic Number and you may change the
state of the Doubler
Harmonic The External Mixer switches the Harmonic Number in the middle of the sweep. The LO Doubler may be on
2368 Spectrum Analyzer Mode User's &Programmer's Reference

Keysight x-series Specifications

General

Analysis Bandwidth	Up to 1 GHz (depending on model)
Real-Time Bandwidth	Up to 1 GHz (depending on model)
Form Factor	Benchtop
Connectivity	LAN, USB, GPIB
Resolution Bandwidth	1 Hz to 10 MHz (depending on model)
