3 Spectrum Analyzer Mode
3.13 Phase and Amplitude vs Time Measurement
3.13.5.2 View
Contains controls for selecting the current View, and for editing User Views.
Views
The PAvT measurement has one view: "Normal" on page 1998.
This is a multiple-window View. When in a multiple-window View, you select a
window by touching it. The menu controls may sometimes change depending on
which window is selected.
Normal
Windows: "Graph" on page 1950, "Results" on page 1950
The PAvT measurement provides tabular result and graphical display.
User View
Lets you choose a View from the saved User Views for the current measurement.
This panel only appears if a User View exists for the current measurement.
Remote
Command
:DISPlay:VIEW:ADVanced:SELect
<alphanumeric>
:DISPlay:VIEW:ADVanced:SELect?
Example Select Baseband as the current View
:DISP:VIEW:ADV:SEL “Baseband”
Notes You must be in the measurement whose View you are trying to set to send the command. You can only
set Views for the current measurement using this command
For predefined views, the parameter is derived from the view name that is shown in the View list in the
user interface. For example, if you are trying to select the Trace Zoom view in the Swept SA
measurement, you send:
:DISP:VIEW:ADV:SEL "Trace Zoom"
because “Trace Zoom” is the name of the View as seen in the Mode/Meas dialog or in the Display, View
menu
You cannot use the legacy View parameter (which in this case would be TZOom) with
:DISP:VIEW:ADV:SEL
<alphanumeric> is case insensitive; you can specify mixed case, however the name will be
evaluated on a single case. Thus, both of the following forms work:
:DISP:VIEW:ADV:SEL "Trace Zoom"
:DISP:VIEW:ADV:SEL "TRACE ZOOM"
1998 Spectrum Analyzer Mode User's &Programmer's Reference
