3 Spectrum Analyzer Mode
3.5 ACP Measurement
MSR, LTEAFDD, LTEATDD and 5G NR Modes support only Integration BW, Filtered IBW and Fast
Power methods
Dependencies When RBW, FAST or FPOWer is selected, Gate function is not available. If you try to turn GateON
while Meas Method is RBW, FAST or FPOWer, an error is generated
When Gate function is ON, RBW, FAST and FPOWer are not available. If you try to change Meas
Method to RBW, FAST or FPOWer, an error is generated
VXT Models M9420A/10A/11A support only the Integration BW method
Couplings IBW (Range) restricts the Res BW available for making this measurement to 30 kHz. When selected,
Res BW is clipped to this value if required and an error number displayed
Preset
IBW
State Saved Saved in instrument state
Range
IBW|IBWRange|FAST|RBW|FPOWer
Backwards
Compatibility SCPI
[:SENSe]:ACPR:SWEep:TYPE
(Power Suite, WCDMA)
[:SENSe]:MCPower:METHod
Carrier/Offset/Limits Config
Opens a dialog that lets you set Carriers, Offset, and Limits parameters.
Carrier
Lets you configure your carriers, carrier spacing, noise bandwidth and measurement
method.
Dependencies Appears in all Modes except MSR, LTEAFDD, LTEATDD and 5G NR
Number of Carriers
This is the same as "Number of Carriers" on page 1014 under Reference.
Couple to #1
Couples carrier settings to carrier #1. The coupled parameters are:
–
"Carrier Pwr Present" on page 1016
–
"Carrier Spacing" on page 1017
–
"Measurement Noise Bandwidth" on page 1017
972 Spectrum Analyzer Mode User's &Programmer's Reference
