Keysight x-series User Manual

6 Input/Output
6.1 RF Source
Band Standard SCPI Example
N 66 5G NR
:SOUR:LIST:STEP2:SET:RAD:BAND N66
N 70 5G NR
:SOUR:LIST:STEP2:SET:RAD:BAND N70
N 71 5G NR
:SOUR:LIST:STEP2:SET:RAD:BAND N71
N 74 5G NR
:SOUR:LIST:STEP2:SET:RAD:BAND N74
N 75 5G NR
:SOUR:LIST:STEP2:SET:RAD:BAND N75
N 76 5G NR
:SOUR:LIST:STEP2:SET:RAD:BAND N76
N 77 5G NR
:SOUR:LIST:STEP2:SET:RAD:BAND N77
N 78 5G NR
:SOUR:LIST:STEP2:SET:RAD:BAND N78
N 79 5G NR
:SOUR:LIST:STEP2:SET:RAD:BAND N79
N 80 5G NR
:SOUR:LIST:STEP2:SET:RAD:BAND N80
N 81 5G NR
:SOUR:LIST:STEP2:SET:RAD:BAND N81
N 82 5G NR
:SOUR:LIST:STEP2:SET:RAD:BAND N82
N 83 5G NR
:SOUR:LIST:STEP2:SET:RAD:BAND N83
N 84 5G NR
:SOUR:LIST:STEP2:SET:RAD:BAND N84
N 86 5G NR
:SOUR:LIST:STEP2:SET:RAD:BAND N86
N 257 5G NR
:SOUR:LIST:STEP2:SET:RAD:BAND N257
N 258 5G NR
:SOUR:LIST:STEP2:SET:RAD:BAND N258
N 260 5G NR
:SOUR:LIST:STEP2:SET:RAD:BAND N260
N 261 5G NR
:SOUR:LIST:STEP2:SET:RAD:BAND N261
Device
Lets you specify the radio band link direction for the steps within the list sequence.
The link is used in conjunction with the channel band and channel number to
determine the output frequency.
Setting Option Description
Uplink
UP
The source calculates the uplink frequency according to an uplink
formula together with selected channel band and channel number
Downlink
DOWN
The source calculates the downlink frequency according to a
downlink formula together with selected channel band and channel
number
Remote Command
:SOURce:LIST:STEP[1]|2|…|1000:SETup:RADio:BAND:LINK DOWN | UP
:SOURce:LIST:STEP[1]|2|…|1000:SETup:RADio:BAND:LINK?
Example
:SOUR:LIST:STEP2:SET:RAD:BAND:LINK UP
:SOUR:LIST:STEP2:SET:RAD:BAND:LINK?
Notes SCPI is supported after A.09.40
2246 Spectrum Analyzer Mode User's &Programmer's Reference
