3 Spectrum Analyzer Mode
3.8 Spurious Emissions Measurement
WLAN Mode:
-36dBm, -36dBm, -36dBm, -30dBm, -50dBm, -50dBm, -50dBm, -50dBm, -50dBm, -50dBm, -
50dBm, -50dBm, -50dBm, -50dBm, -50dBm, -50dBm, -50dBm, -50dBm, -50dBm, -50dBm
State Saved Saved in instrument state
Min/Max -200.0 dBm/50.0 dBm
Auto Function
Remote
Command
:CALCulate:SPURious[:RANGe][:LIST]:LIMit:ABSolute[:UPPer]:DATA:STOP:AUTO OFF
| ON | 0 | 1, OFF | ON | 0 | 1, OFF | ON | 0 | 1, OFF | ON | 0 | 1, OFF | ON
| 0 | 1, OFF | ON | 0 | 1, OFF | ON | 0 | 1, OFF | ON | 0 | 1, OFF | ON | 0 |
1, OFF | ON | 0 | 1, OFF | ON | 0 | 1, OFF | ON | 0 | 1, OFF | ON | 0 | 1,
OFF | ON | 0 | 1, OFF | ON | 0 | 1, OFF | ON | 0 | 1, OFF | ON | 0 | 1, OFF |
ON | 0 | 1, OFF | ON | 0 | 1, OFF | ON | 0 | 1
:CALCulate:SPURious[:RANGe][:LIST]:LIMit:ABSolute[:UPPer]:DATA:STOP:AUTO?
Example
:CALC:SPUR:LIM:ABS:DATA:STOP:AUTO ON, ON, ON, ON, ON, ON, ON, ON, ON, ON, ON,
ON, ON, ON, ON, ON, ON, ON, ON, ON
:CALC:SPUR:LIM:ABS:DATA:STOP:AUTO?
Preset
ON, ON, ON, ON, ON, ON, ON, ON, ON, ON, ON, ON, ON, ON, ON, ON, ON, ON, ON,
ON
State Saved Saved in instrument state
Peak Excursion
Sets the minimum amplitude variation of signals that can be identified as peaks. If a
value of 6 dB is selected, peaks that rise and fall more than 6 dB above the peak
threshold value are identified.
This parameter can send up to 20 values. The location in the list sent corresponds to
the range of the associated value. When sending the remote command, missing
values are not permitted. If you want to change values 2 and 6 you must send all
values up to 6. Subsequent values will remain as they were.
The query for this parameter always returns 20 values.
Remote
Command
[:SENSe]:SPURious[:RANGe][:LIST]:PEAK:EXCursion <rel_ampl>, <rel_ampl>, <rel_
ampl>, <rel_ampl>, <rel_ampl>, <rel_ampl>, <rel_ampl>, <rel_ampl>, <rel_
ampl>, <rel_ampl>, <rel_ampl>, <rel_ampl>, <rel_ampl>, <rel_ampl>, <rel_
ampl>, <rel_ampl>, <rel_ampl>, <rel_ampl>, <rel_ampl>, <rel_ampl>
[:SENSe]:SPURious[:RANGe][:LIST]:PEAK:EXCursion?
Example
:SPUR:PEAK:EXC 20,20, 20, 20, 20, 20, 20, 20, 20, 20, 20, 20, 20, 20, 20, 20,
20, 20, 20, 20
:SPUR:PEAK:EXC?
Preset +6.00000000E+000, +6.00000000E+000, +6.00000000E+000, +6.00000000E+000,
+6.00000000E+000, +6.00000000E+000, +6.00000000E+000, +6.00000000E+000,
+6.00000000E+000, +6.00000000E+000, +6.00000000E+000, +6.00000000E+000,
1468 Spectrum Analyzer Mode User's &Programmer's Reference
