Keysight x-series User Manual

3 Spectrum Analyzer Mode
3.9 SEM Measurement
Radio Std Presets
MHz/ 40 MHz/ 80 MHz/
160 MHz)
40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00
dB, -40.00 dB
802.11be (320 MHz) -20.00 dB, -28.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -
40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00
dB, -40.00 dB
802.11ac/ax (80 MHz +
80MHz)
-40dB, -28.00 dB, -20.00 dB, 0 dB, -20.00 dB, -28.00 dB, -40.00 dB, -
40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00
dB
802.11ah (1MHz/ 2
MHz/ 4 MHz/ 8 MHz/
16 MHz)
-20.00 dB, -28.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -
40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00
dB, -40.00 dB
802.11 j/p 10M, p5M -20.00 dB, -28.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -47.00 dB, -
47.00 dB, -47.00 dB, -47.00 dB, -47.00 dB, -47.00 dB, -47.00 dB, -40.00
dB, -40.00 dB
802.11af (6MHz/
7MHz/ 8MHz)
-20.00 dB, -28.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -
40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00 dB, -40.00
dB, -40.00 dB
WLAN Mode Auto Function Presets
Radio Std Presets
802.11a/g (OFDM/DSSS-OFDM)
802.11n (20MHz/ 40MHz)
OFF, OFF, OFF, ON, ON, ON, ON, ON, ON, ON, ON,
ON, ON, ON
802.11b/g (DSSS/CCK/PBCC)
ON, ON, ON, ON, ON, ON, ON, ON, ON, ON, ON,
ON, ON, ON
802.11ac/ax/be (20 MHz/ 40 MHz/
80 MHz/ 160 MHz)
OFF, OFF, OFF, ON, ON, ON, ON, ON, ON, ON, ON,
ON, ON, ON
802.11be (320 MHz)
OFF, OFF, OFF, ON, ON, ON, ON, ON, ON, ON, ON,
ON, ON, ON
802.11ac/ax (80 MHz + 80MHz)
OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF,
OFF, OFF, OFF, OFF, OFF
802.11ah (1MHz/2 MHz/ 4 MHz/ 8
MHz/ 16 MHz)
OFF, OFF, OFF, ON, ON, ON, ON, ON, ON, ON, ON,
ON, ON, ON
802.11j/p (20M/ 10M) /11p(5M)
OFF, OFF, OFF, ON, ON, ON, ON, ON, ON, ON, ON,
ON, ON, ON
802.11af (6 MHz/ 7 MHz/ 8 MHz)
OFF, OFF, OFF, ON, ON, ON, ON, ON, ON, ON, ON,
ON, ON, ON
Fail Mask
Selects one of the logics for fail conditions between the measurement results and
the test limits:
Spectrum Analyzer Mode User's &Programmer's Reference 1659

Keysight x-series Specifications

General

Analysis Bandwidth	Up to 1 GHz (depending on model)
Real-Time Bandwidth	Up to 1 GHz (depending on model)
Form Factor	Benchtop
Connectivity	LAN, USB, GPIB
Resolution Bandwidth	1 Hz to 10 MHz (depending on model)
