3 Spectrum Analyzer Mode
3.5 ACP Measurement
Remote Command
[:SENSe]:ACPower:IF:GAIN:FPOWer <integer>
[:SENSe]:ACPower:IF:GAIN:FPOWer?
Example
:ACP:IF:GAIN:FPOW 10
:ACP:IF:GAIN:FPOW?
Dependencies Grayed-out when "Meas Method" on page 970 is not Fast Power
Not available in VXT models M9410A/11A/15A
Preset 0
State Saved Saved in instrument state
Min/Max -20/20
Integration BW
Selects an Integration BW passband from either -3 dB (DB3) or -6 dB (DB6).
Remote Command
[:SENSe]:ACPower:FILTer:BANDwidth[:INTegration] DB3 | DB6
[:SENSe]:ACPower:FILTer:BANDwidth[:INTegration]?
Example
:ACP:FILT:BAND DB3
:ACP:FILT:BAND?
Dependencies Applicable for carriers and offsets whose filter method is not RRC, and when "Meas Method" on page
970 is other than RBW
Preset
DB3
State Saved Saved in instrument state
Range -3 dB|-6 dB
3.5.13.5 Global
The controls in this menu apply to all Modes in the instrument.
Some controls (for example, "Global Center Freq" on page 2034) allow you to switch
certain Meas Global parameters to a Mode Global state. These switches apply to all
Modes that support global settings. For example, no matter what Mode you are in
when you set Global Center Freq to ON, it applies to all Modes that support Global
settings.
Other controls (for example, Extend Low Band) are actually set in this menu, but
apply to all Modes.
Global Center Freq
The software maintains a Mode Global value called Global Center Freq.
Spectrum Analyzer Mode User's &Programmer's Reference 1091
