6 Input/Output

6.9 Calibration

If there are multiple Cals being executed in a Cal Group, this dialog advises you

when each Cal is complete. It also provides the ability to abort the Execute Cal

Request.If you choose to abort, calibrations that have completed use the new Cal

data and update the Last Cal field. Calibrations that have not completed retain the

existing Cal data and Last Cal timestamp, or show “---” if the Cal had never been

executed.

Remote Command

:SYSTem:CALibration:INITiate:SELected

Example

:SYST:CAL:INIT:SEL

Notes Cals cannot be applied until they have been calibrated. Once a Cal has been calibrated, the Last Cal

field in the table displays the date and time the Cal was last calibrated

Dependencies Applied to the currently selected Cal Group

Couplings Calibrate Selected is disabled if there are no Calibrate checkboxes checked. If the disabled control is

selected, the advisory message “Check the Calibrate box for the Cals you want to calibrate” is

displayed

6.9.1.3 Apply Cal Group

This is the same as "Apply Cal Group" on page 2518 in the Calibration tab.

6.9.1.4 Abort Calibration

Aborts the Calibration routine of the currently selected Cal Group

Remote Command

:SYSTem:CALibration:ABORt

Example

:SYST:CAL:ABOR

Dependencies Aborts the currently running calibration. The previously-run calibrations will still be available, but the

current calibration is halted, and next calibrations selected are not executed. Once the calibration

starts, the modal dialog appears, and the abort can be executed by selecting Cancel

2486 Spectrum Analyzer Mode User's &Programmer's Reference
