8 Trigger
8.1 Trigger
:TRIG:FRAM:SYNC RFB
:TRIG:FRAM:SYNC OFF
Dependencies Only appears when Periodic Timer is selected as the Trigger or Gate Source
Preset
OFF
State Saved Saved in instrument state
8.1.13 TV Line
Selects the TV Line number on which to trigger. Line number range is dependent on
the settings of the "Standard" on page 2675 and "Field" on page 2675menus within
the TV trigger setup functions. When the line number is incremented beyond the
upper limit, the value will change to the lower limit and continue incrementing from
there. When the line number is decremented below the lower limit, the value will
change to the upper limit and continue decrementing from there.
Remote Command
:TRIGger[:SEQuence]:TV:LINE <integer>
:TRIGger[:SEQuence]:TV:LINE?
Example
:TRIG:TV:LINE 20
:TRIG:TV:LINE?
Dependencies Only available in the Swept SA measurement
Only appears when TV is selected as the Trigger Source
Preset 17
State Saved Saved in instrument state
Min 1
The minimum value is the minimum line and rolls over to the maximum value. The minimum line
number depends on which Field and standard are selected
Max The maximum value is the maximum line and rolls over to the minimum value. The maximum line
number depends on which Field and standard are selected
Field 1 (ODD):
–
Maximum line is 263 for formats NTSC-M, NTSC-Japan, NTSC-4.43, PAL-M and PAL-60
–
Maximum line is 313 for formats PAL-B, D, G, H, I, PAL-N, PAL-N Combin, and SECAM-L
Field 2 (EVEN):
–
The maximum line 262 for formats NTSC-M, NTSC-Japan, NTSC-4.43, PAL-M and PAL-60
–
The maximum line is 312 for formats PAL-B, D, G, H, I, PAL-N, PAL-N Combin, and SECAM-L
Field = ENTire Frame:
–
525, for formats NTSC-M, NTSC-Japan, NTSC-4.43, PAL-M and PAL-60
–
625, for formats PAL-B, D, G, H, I, PAL-N, PAL-N Combin, and SECAM-L
Spectrum Analyzer Mode User's &Programmer's Reference 2674
