3 Spectrum Analyzer Mode
3.5 ACP Measurement
Couplings Coupled to "Scale Range" on page 1556 as follows:
Scale/Div = Scale Range/10 (number of divisions)
When "Auto Scaling" on page 896 is ON, this value is automatically determined by the measurement
result
When you change a value, Auto Scaling automatically changes to Off
Preset 10.00 dB / Div
State Saved Saved in instrument state
Min 0.10 dB
Max 20 dB
Annotation <value> dB/ left upper of graph
Backwards
Compatibility
SCPI
:DISPlay:ACPower:VIEW[1]:WINDow[1]:TRACe:Y[:SCALe]:PDIVision
Scale Range
Sets the Y-Axis scale range.
Remote Command Replace <meas> with the identifier for the current measurement
:DISPlay:<meas>:WINDow[1]:TRACe:Y[:SCALe]:RANGe <rel_ampl>
:DISPlay:<meas>:WINDow[1]:TRACe:Y[:SCALe]:RANGe?
Example
:DISP:CHP:WIND:TRAC:Y:RANG 100
:DISP:CHP:WIND:TRAC:Y:RANG?
Couplings Coupled to Scale/Div as follows
Scale Range = Scale/Div * 10 (number of divisions)
When you change this value, Auto Scaling automatically changes to OFF
Preset 100 dB
State Saved Saved in instrument state
Min 1
Max 200
Y Axis Unit
Displays a dropdown menu that enables you to change the vertical (Y) axis
amplitude unit. This setting affects how the data is read over the remote interface.
When using the remote interface, only numerical values are returned, so you must
know what the Y Axis Unit is to interpret the results. This is described in more detail
in "Amplitude Data Query and Y Axis Unit" on page 892 below.
Spectrum Analyzer Mode User's &Programmer's Reference 889
